SG4-B Series

Instruction Manual

10. TECHNICAL DATA

ELECTRICAL DATA
Power supply (Vdd):

24 Vdc ±

20%

Consumption (TX):

2.5 W max

Consumption (RX):

3.5 W max (without load)

Outputs: 2

PNP

Short-circuit protection:

1.4 A max

Output current:

0.5 A max / each output

Output voltage – status ON:

Vdd –1 V min

Output voltage – status OFF:

0.2 V max

Capacitive load

2.2 uF @ 24Vdc max

Response times:

See table below

Controlled height:

150..1800 mm

Safety category:

Type 4

Auxiliary functions:

Test; manual/automatic restart; EDM;
RESET

Electrical protection:

Class I / Class III

(see paragraph 4.2)

Connections:

M12 4-pole for emitter
M12 8-pole for receiver

Cable length (for power supply):

50 m. max

OPTICAL DATA
Light emission (

 ):

Infrared, LED (950 nm)

Resolution:

14 - 30 mm

Operating distance:

0.2…19 m for 30 mm
0.2…6 m for 14 mm

Ambient light rejection:

IEC-61496-2

MECHANICAL AND ENVIRONMENTAL DATA
Operating temperature:

0…+ 55 °C

Storage temperature:

- 25…+ 70 °C

Temperature class:

Humidity:

15…95 % (no condensation)

Mechanical protection:

IP 65 (EN 60529)

Vibrations:

Width 0.35 mm, Frequency 10 … 55 Hz
20 sweep per axis, 1 octave/min
(EN 60068-2-6)

Shock resistance:

16 ms (10 G) 1,000 shocks per axis
(EN 60068-2-29)

Housing material:

Painted aluminium (yellow RAL 1003)

Front glass material:

PMMA

Cap material:

PC MAKROLON

Weight:

1.3 kg / meter for each single unit
