Table 2-12 bottom hook – dimensions – Harrington Hoists and Cranes RH Wire Rope Hoist User Manual
Page 18
18
Table 2-12 Bottom Hook – Dimensions
Capacity
(Tons)
Product Code
a
(in)
b
(in)
c
(in)
d
(in)
e
(in)
f
(in)
g
(in)
h
(in)
2
RH02S-20
4C-
2.2
1.8
1.9
1.5
2.2
2.5
1.5
5.7
RH02S-29
4C-
RH02S-20
4D-
RH02S-29
4D-
RH02D-39
3A-
1.7
1.4
1.5
1.1
1.9
2.1
1.3
4.7
RH02D-79
3A-
3
RH03D-20
4C-
2.2
1.8
1.9
1.5
2.2
2.5
1.5
5.7
RH03D-29
4C-
RH03D-23
4H-
2.6
2.1
2.3
1.8
2.5
2.8
1.7
6.7
RH03D-33
4H-
RH03D-46
3E-
2.2
1.8
1.9
1.5
2.2
2.5
1.5
5.7
RH03D-85
3E-
5
RH05D-23
4G-
2.6
2.1
2.3
1.8
2.5
2.8
1.7
6.7
RH05D-33
4G-
RH05D-23
4M-
3.5
2.8
3.0
2.4
3.1
3.5
2.0
8.9
RH05D-33
4M-
RH05D-46
4J-
2.6
2.1
2.3
1.8
2.5
2.8
1.7
6.7
RH05D-92
4J-
RH05D-52
4P-
3.5
2.8
3.0
2.4
3.1
3.5
2.0
8.9
RH05D-X5
4P-
7 1/2
RH08D-23
4L-
3.5
2.8
3.0
2.4
3.1
3.5
2.0
8.9
RH08D-33
4L-
RH08D-23
3M-
RH08D-33
3M-
RH08D-52
4N-
RH08D-X5
4N-
10
RH10D-23
4L-
3.5
2.8
3.0
2.4
3.1
3.5
2.0
8.9
RH10D-33
4L-
RH10D-26
4R-
4.9
3.9
4.2
3.3
4.4
5.0
3.0
12.7
RH10D-36
4R-
RH10D-52
3N-
3.5
2.8
3.0
2.4
3.1
3.5
2.0
8.9
RH10D-X5
3N-
15
RH15D-26
4Q-
4.9
3.9
4.2
3.3
4.4
5.0
3.0
12.7
RH15D-36
4Q-
20
RH20D-26
3Q-
4.9
3.9
4.2
3.3
4.4
5.0
3.0
12.7
RH20D-36
3Q-
