Table 2-5 Standard Headroom Trolley Hoists – Trolley Specifications
Capacity
(Tons)
Product Code
Standard
Flange Range
B*
(in)
Traversing Motors
Single Speed
40 ft/min
Single Speed
64 and 80 ft/min
Dual Speed
64/16 and 80/20 ft/min
Output
(Hp)
Rated Current
(amps)
Output
(Hp)
Rated Current
(amps)
Output
(Hp)
Rated Current
(amps)
@460V @230V
@460V @230V
@460V
@230V
2
RH02S-20
4C-
-
3.54 to 11.02
0.32
1.1
2.2
0.6
1.1
3.0
0.6/0.13
1.3/1.1
2.5/2.2
RH02S-29
4C-
-
RH02S-20
4D-
-
RH02S-29
4D-
-
RH02S-39
3A-
-
RH02S-79
3A-
-
3
RH03S-20
4C-
-
3.54 to 11.02
0.32
1.1
2.2
0.6
1.1
3.0
0.6/0.13
1.3/1.1
2.5/2.2
RH03S-29
4C-
-
RH03S-23
4H-
-
4.69 to 11.02
RH03S-33
4H-
-
RH03S-46
3E-
-
3.54 to 11.02
RH03S-85
3E-
-
5
RH05S-23
4G-
-
4.69 to 11.02
0.32
1.1
2.2
0.6
1.1
3.0
0.6/0.13
1.3/1.1
2.5/2.2
RH05S-33
4G-
-
RH05S-23
4M-
-
5.31 to 11.02
0.5
0.9
1.5
4.4
0.9/0.2
2.1/1.1
4.2/2.2
RH05S-33
4M-
-
RH05S-46
4J-
-
4.69 to 11.02
0.32
0.6
1.1
3.0
0.6/0.13
1.3/1.1
2.5/2.2
RH05S-92
4J-
-
RH05S-52
4P-
-
5.31 to 11.02
0.5
0.9
1.5
4.4
0.9/0.2
2.1/1.1
4.2/2.2
RH05S-X5
4P-
-
7 1/2
RH08S-23
4L-
-
5.31 to 11.02
0.5
1.1
2.2
0.9
1.5
4.4
0.9/0.2
2.1/1.1
4.2/2.2
RH08S-33
4L-
-
RH08S-23
3M-
-
RH08S-33
3M-
-
RH08S-52
4N-
-
RH08S-X5
4N-
-
10
RH10S-23
4L-
-
5.31 to 11.02
0.5
1.1
2.2
0.9
1.5
4.4
0.9/0.2
2.1/1.1
4.2/2.2
RH10S-33
4L-
-
RH10S-26
4R-
-
6.69 to 11.02
RH10S-36
4R-
-
RH10S-52
3N-
-
5.31 to 11.02
RH10S-X5
3N-
-
15**
RH15S-26
4Q-
-
6.69 to 11.02
0.5 x 2 1.1 x 2 2.2 x 2 0.9 x 2 1.5 x 2 4.4 x 2 0.9/0.2 x 2 2.1/1.1 x 2 4.2/2.2 x 2
RH15S-36
4Q-
-
20**
RH20S-26
3Q-
-
6.69 to 11.02
0.5 x 2 1.1 x 2 2.2 x 2 0.9 x 2 1.5 x 2 4.4 x 2 0.9/0.2 x 2 2.1/1.1 x 2 4.2/2.2 x 2
RH20S-36
3Q-
-
*Optional wider flange ranges available. Wider flange range is the standard lower value to 15.75 inch.
Example: Wider flange range for 2 Ton trolley hoists is 3.54 to 15.75 inches.
**15 and 20 Ton models are equipped with 2 trolley motors.
