8
2.0 Technical Information
2.1 Specifications
2.1.1 Product Code:
2.1.2 Hoist and Trolley Size – The RH Advantage trolley hoists are available in 2 basic sizes. These sizes
are referred to throughout this manual to identify what information applies to which trolley hoist. The
10
th digit in the product code designates the sizes as shown in Table 2-1 below.
Table 2-1 Hoist and Trolley Sizes
10 TH Digit in
Product Code
Hoist Size Trolley Size
G 2 2
L 3 3
2.1.3 Operating Conditions and Environment
Temperature Range: +14 ° to +104°F (-10° to +40°C)
Humidity: 80% or less
Electrical Enclosure Rating: IP55
Brake Enclosure Rating: IP23
Supply Voltage: 230V-3ph-60Hz or 460V-3ph-60Hz
Control Voltage: 110V-1ph-60Hz
-
