14
3.2.2 Lift points – The Advantage trolley hoists are equipped with lifting lugs to facilitate lifting the trolley
hoist with a hoist or crane (see
Figure 3-4 ). During lifting do NOT support the trolley hoist any other
way.
Figure 3-4 Lift Points
3.3 Mounting Location
3.3.1
WARNING
Prior to mounting the trolley hoist ensure that the trolley beam and its supporting
structure are adequate to support the trolley hoist and its load. If necessary consult a professional that
is qualified to evaluate the adequacy of the suspension location and its supporting structure.
3.3.2 Ensure that there is adequate vertical and horizontal clearance along the entire range of the trolley
hoist’s motion (see
Figure 3-5 ).
3.3.3
NOTICE
See Section 6.6 for outdoor installation considerations.
Figure 3-5 Trolley Hoist Clearances
