12


Table 2-8

Trolley Wheel – Dimensions

Capacity

(Tons)

Product Code

a

(in)

b

(in)

i

(in)

Wheel

Dia.

∅

R

(in)

Maximum

Flange

Thickness

t

(in)

RH05U23D4G-

1

-WA

5

RH05U33D4G-

1

-WA

RH08U23D3G-

1

-WA

7 ½

RH08U33D3G-

1

-WA

1.38

1.14

0.47

4.92

0.91

RH10U23D4L-

1

-WA

10

RH10U33D4L-

1

-WA

1.77

1.50

0.75

7.87

1.50

Note: See Ultra- Low Headroom Trolley Wheel Reaction Forces

Table 2-7

for reaction forces R1 and R2.
