Part name – Harrington Hoists and Cranes TCR Hoist - (1/4-6 Ton) User Manual
Page 68
Figure
Number
Part Number
Part Name
Parts
Per
Handle
152
TCR132506012 SLOTTED HEAD MACHINE SCREW
1
154
TCR426221E20 HOSE NIPPLE
3
155
TCR136102094 SEAL WASHER
3
160
TCR42622452D PENDANT HANDLE CP
1
160A
TCR426224520 CONTROL HANDLE
1
160B
TCR130501004 STEEL BALL
2
160C
TCR130802255 PENDANT VALVE SPRING
2
160D
TCR426221H30 PENDANT VALVE SEAT
2
160E
TCR131103008 O-RING
4
160F
TCR426224480 CONTROL SPOOL
2
160G
TCR426224530 CONTROL BUSH
2
160H
TCR426221H60 PUSH ROD
2
160J
TCR136602023 VALVE LEVER (U)
1
160K
TCR136602024 VALVE LEVER (D)
1
160L
TCR130402006 LEVER PIN
1
160M
TCR426221H90 BUFFER SLEEVE
2
160N
TCR130305007 CIR-CLIP
2
160P
TCR130802256 BUFFER SPRING
2
160Q
TCR426221J20 BUFFER ROD
2
160R
TCR132112010 SET SCREW
2
160S
TCR426221J40 HANDLE COVER
1
160T
TCR132805010 HEX FLAT HEAD MACHINE SCREW
4
160U
TCR132105005 SET SCREW
2
P
en
dant
H
a
ndl
e
68
