Harrington Hoists and Cranes TCR Hoist - (1/4-6 Ton) - Manual (Page 65)

Figure
Number
Part Number
Part Name
Parts
Per
Hoist
TCR250P
TCR500P
TCR1000P2
TCR1000P
TCR2000P2
TCR3000P
TCR6000P2
1 TCR426224012 TCR426325010 MAIN SPOOL 1
2 TCR426224020 BRAKE SPOOL 1
3 TCR426224030 SPOOL RETAINER 4
4 TCR426224040 BRAKE RETAINER 1
5 TCR426224050 BRAKE NUT 1
6
TCR426224061 TCR426325060 VALVE BODY Version 1 & A
1
TCR426224062 TCR426325061 VALVE BODY Version B
7 TCR426224070 TOP COVER 1
8
TCR426224081 SIDE COVER (L) Version 1 & A
1
TCR426224082 SIDE COVER (L) Version B
9
TCR426224091 SIDE COVER (R) Version 1 & A 1
TCR426224092 SIDE COVER (R) Version B
10 TCR426224100 LIMIT GUIDE 1
14 TCR136102160 SIDE PACKING 2
15 TCR426224140 LIMIT LEVER 1
16 TCR130802210 BRAKE SPRING 2
17 TCR130802211 LIMIT SPRING 1
18 TCR136102161 VALVE PACKING 1
19 TCR426224A90 EXHAUST PLATE 1
20 TCR136102162 TCR136102192 TOP PACKING 1
21 9047219 RETAINING RING 4
22 9047258 RETAINING RING 1
23 9091247 SOCKET BOLT 6
24 9091253 SOCKET BOLT 3
25 9091258 SOCKET BOLT 3
26 9093420 HEX NUT 1
27 9098506 U-NUT 1
29 TCR132306028 SET SCREW 1
30 TCR137402031 NYLON SILENCER 1
31 TCR134902003 HEX SOCKET PIPE PLUG 3
32 TCR130604010 SPRING PIN 2
33 TCR130821418 SPRING 1
Figure
Number
Part Number
Part Name
Parts
Per
Hoist
TCR250P
TCR500P
TCR1000P2
TCR1000P
TCR2000P2
TCR3000P
TCR6000P2
34 TCR136102163 UNDER PACKING 1
67* TCR426224110 TCR426325113 CHAIN LEVER* 1
68 TCR426224120 ROLLER SHAFT 1
68A TCR132108016 SET SCREW 1
69 TCR426224130 LIMIT ROLLER 1
69A* TCR426325740 CAM* 1
134
TCR137309277 NAME PLATE 250
1
TCR137309276 NAME PLATE 500
TCR137309278 NAME PLATE 1000, 1000-2
TCR137309280 NAME PLATE 2000-2
TCR137309282 NAME PLATE 3000
TCR137309288 NAME PLATE 6000-2
140** TCR426224461 TCR426325461 LIMIT SHAFT** 1
141 TCR130802214 TCR130821123 MAIN SPRING 2
142 TCR426224471 UNDER COVER 1
148 9047110 RETAINING RING 1
149 9047112 RETAINING RING Version 1 1
151 TCR132805010
HEX FLAT HEAD MACHINE
SCREW
4
152 TCR132506012
SLOTTED HEAD MACHINE
SCREW
2
153 TCR137240020 PENDANT HOSE ASSY. FT***
154 TCR426221E20 HOSE NIPPLE Version 1 & A 3
155 TCR136102094 SEAL WASHER Version 1 & A 3
156 TCR130790012 HAIRPIN COTTER Versions A & B 1
157 TCR426325750 WASHER Version A & B 1
158 9013137 90° TUBE FITTING Version B 3
165 TCR1350005HH TCR420845DHH HOSE STEM ASSY. 1
180 WTAG7 WARNING TAG 1
* Replacing the one-piece Chain Lever (#67) on 3 and 6 Ton version 1 hoists.
Hoist requires figure numbers 67 and 69A.
** Replacing limit shaft (#140) on version 1 hoists requires figure numbers 140, 156 and 157.
*** Specify the hoist’s lift or the required pendant drop when ordering.
