Harrington Hoists and Cranes TCS Hoist User Manual
Page 49
Brake, Gears and Load Suspension Components
49
Figure
Number
Name
Parts
per
hoist
Part Number
100
Center Housing
1
TCS426230A00
101
Load Sheave
1
TCS426230A50
102
Coupling
1
TCS426230200
103
Chain Guide
1
TCS426230350
104
Chain Separator
1
TCS426230360
105
Bearing
2
9000508
106
Socket Bolt
4
9091250
107
Set Screw
1
TCS132106006
108
O-Ring
1
TCS131103006
109
O-Ring
1
TCS131103052
110
O-Ring
1
TCS131117043
111
Spring Pin
2
TCS130608060
113
Chain Container Assembly
0
TCSS2623055C
114
Load Chain
0
LCER005NP
150
Brake Cover
1
TCS426230410
151
Brake Piston
1
TCS426230400
152
Brake Disk
1
TCS426230430
153
Disk Spring
6
TCR130802213
154
Name Plate
TCS 250
1
TCS137301067
TCS 500
1
TCS137301063
TCS 1000
1
TCS137301065
155
Socket Bolt
4
9091255
156
Set Screw
1
TCR132105005
157
O-Ring
1
TCS131103052
158
O-Ring
1
TCS131103045
200
Gear Case
1
TCS426230310
201
First Pinion
TCS 250
1
TCS426351A60
TCS 500/1000
TCS426230A60
202
First Star
Gear
TCS 250
3
TCS426351A70
TCS 500/1000
TCS426230A70
203
First Pin
3
TCS426230A80
204
First Ring Gear
1
TCS426230E10
205
Second
Pinion
TCS 250
1
TCS426351E20
TCS 500/1000
TCS426230E20
206
Second Star Gear
3
TCS426230E30
207
Second Pin
3
TCS426230E40
208
Second Ring Gear
1
TCS426230E50
209
Cage
1
TCS426230240
210
Lock Screw
1
TCS426230890
211
Brake Plate
1
TCS426230900
Figure
Number
Name
Parts
per
hoist
Part Number
212
Bearing
2
TCS130113001
213
Bearing
1
TCS130120004
214
Bearing
1
9000105
215
Needle Bearing
3
TCS130131020
216
Needle Bearing
3
TCS130131212
217
Socket Bolt
3
9091250
218
Button Head Screw
1
9738076
219
Washer
3
TCS131307012
220
Washer
1
9012513
221
O-Ring
1
TCS131103006
222
O-Ring
1
TCS131103052
223
Spring Pin
1
9148125
224
Spring Pin
2
9148198
225
Retaining Ring
3
9047112
250
Top Hook Complete Set
1
60913
250A Top Hook Assembly
1
60914
251 Hook Latch
1
AH420620P10
252 Spring Pin
1
TCR130603024
253
Hook Latch Spring
1
TCR130802046
254
Hook End Piece
1
TCS426230570
255
Hex Flat Head Mach. Screw
2
9096542
260
Bottom Hook
Block Set
TCS 250
1
60915
TCS 500
1
60916
260A Bottom Hook Assembly
1
70007
261 Hook Latch
1
AH420620P10
262 Spring Pin
1
TCR130603024
263 Hook Latch Spring
1
TCR130802046
270
Steel Ball
7
TCR130502020
271
Bottom Hook Holder
1
TCS426230800
272
Swivel Hook Plug
1
TCR420846PY0
273 Sleeve
TCS 250
1
TCS426351760
TCS 500
1
TCS426230760
274
Sleeve Pin
1
TCS426230E70
275
Lock Ring
1
TCS130802286
280
Spring
1
TCR130802219
281
Washer
1
TCS426230G20
