11

Table 2-3

TCS with Cord Control Dimensions

Single Fall Hoist

Double Fall Hoist

Cap.

(Tons)

Product

Code

Headroom

C

(in)

a

(in)

b

(in)

d

(in)

e

(in)

g

(in)

h

in)

i

(in)

j

(in)

1/4

TCS250C

16.3

14.4

8.7

6.3

7.6

1.0

5.3

3.3

1.0

1/2

TCS500C

16.3

14.4

8.7

6.3

7.6

1.0

5.3

3.3

1.0

1

TCS1000C2

17.9

14.4

9.0

6.3

8.0

1.1

6.3

2.8

1.9

Table 2-4

Top and Bottom Hook Dimension*

Units = inch

Product Code

a

b

c

d

e

f

g

h

TCS250C/P

0.6

0.8

0.6

0.8 1.4 1.3

1.0 2.9

TCS500C/P

0.6

0.8

0.6

0.8 1.4 1.3

1.0 2.9

TCS1000C2/P2

1.4

0.9

1.1

0.9 1.6 1.6

1.1 4.2

*Refer to

Section 5.7

for inspection dimensions and limits.
