Motor, valve body and controls, Cord model only, Pendant model only – Harrington Hoists and Cranes TCS Hoist User Manual
Page 47
Motor, Valve Body and Controls
47
Figure
Number
Name
Parts
per
hoist
Part Number
1
Throttle Valve
2
AH420215VB0
2
Valve Bushing (Up)
1
TCS426230E90
3
Valve Bushing (Down)
1
TCS426230F00
4
Spring Seat
2
TCS426230C70
5
Valve Cap
2
TCS426230A20
6
Valve Body
1
TCS426230060
7
Bush Cap
2
TCS426230A30
8
Piston
2
TCS426230C60
9
Exhaust Plate
1
TCS426230810
10
Silencer (S)
4
TCS137402023
11
Adjust Cap
2
TCS426230A10
12
Inlet Bushing
1
TCR134703070
13
Screen
1
TCR136803032
14
Valve Spring
2
AH130802030
15
Spring
2
TCS130802224
16
Valve Gasket
1
TCS136102165
17
Bushing
2
TCS130219705
18
Socket Bolt
4
9091235
19
Button-Head Screw
2
AH131905010
20
Set Screw
2
TCR132105005
21
O-Ring
2
TCR131103005
22
O-Ring
2
AH131103013
23
O-Ring
4
AH131103016
24
O-Ring
2
AH131103017
25
O-Ring
2
TCS131117023
26
O-Ring
2
AH131118012
27
O-Ring
2
TCS131103011
28
Spring Pin
4
9148101
29
Spring Pin
2
TCR130604010
30
Retaining Ring
2
9047112
31
Retaining Ring
2
9047232
32
Retaining Ring
2
9047225
50
Motor Case
1
TCS426230790
51
Rear Plate
1
TCS426230180
52
Cylinder
1
TCS426230160
53
Rotor
1
TCS426230150
54
Front Plate
1
TCS426230170
55
Vane
8
TCS137102032
56
Lift Spring
8
TCR130802212
57
Limit Shaft
1
TCS426230460
58
Limit Shaft Bushing
1
TCS426230A40
59
Limit Lever
1
TCS426230140
60
Bearing
2
TCS130128104
61
Roller Shaft
2
TCS426230120
62
Chain Lever
TCS 1000C2/P2
1
TCS426251110
63
Motor Gasket
1
TCS136102166
64
Silencer (M)
1
TCS137402024
65
Bearing
2
9000102
66
Needle Bearing
2
TCS130151210
67
Socket Bolt
3
9091250
68
Socket Bolt
1
90912147
69
Socket Bolt
2
9091248
70
O-Ring
2
TCS131103012
71
O-Ring
1
TCS131103019
72
O-Ring
1
TCS131102009
73
Spring Pin
1
9148152
75
Spring Pin
1
91481169
76
Retaining Ring
1
9047115
77
Retaining Ring
1
9047228
Figure
Number
Name
Parts
per
hoist
Part Number
78
Hair Pin Cotter
1
AH130790008
79
Retaining Ring
4
TCS130303003
450
Brand Name Plate
1
AH137309264
Cord Model Only:
Figure
Number
Name
Parts
per
hoist
Part Number
62
Chain Lever TCS 250/500
1
TCS426230110
350
Under Cover
1
TCS426233470
352
Socket Bolt
1
9091231
353
Socket Bolt
2
9091229
358
O-Ring
3
TCR131103004
400
S-Type Wire
2
TCR130802081
402
Grip (White, Up)
1
AH136602625
403
Grip (Red, Down)
1
AH136602626
404
Handle
1
AH136602627
401R
Red Cord (Down)
2
9013102
401W
White Cord (Up)
2
9013101
Pendant Model Only:
Figure
Number
Name
Parts
per
hoist
Part Number
62
Chain Lever
TCS 250/500
1
TCS426351110
300A
Pendant Valve Assembly
1
TCS420226VRD
300
Throttle Valve
2
TCS420218VB0
301
Valve Body
1
TCS420226VR0
302
Bushing
2
TCS420218VF0
303
Lever Pin
1
TCS130402071
304
Lever
2
TCS420218VH0
305
Spring
2
TCS130802220
306
Set Screw
1
TCS132106006
307
O-Ring
2
TCS131109001
308
O-Ring
2
TCR131103008
309
O-Ring
2
TCS131103009
330
Hose Fitting
3
TCS135106302
332
Hose Clamp
3
TCS137501013
335
S-Type Wire
1
TCR130802081
337
Cable Tie - Red
4
TCS137502034
338
Cable Tie - White
2
TCS137502036
339
Cable Tie - Black
2
TCS137502037
350
Under Cover
1
TCS426230470
351
Pendant Air Silencer
1
TCS137402033
352
Socket Bolt
1
9091231
353
Socket Bolt
2
9091229
354
Set Screw
2
TCS132105016
355
Set Screw
1
TCR132105005
356
Flat Head Machine Screw
3
9096566
357
Hex Nut
2
9093417
358
O-Ring
3
TCR131103004
359
Boot
1
AH136608250
360
Pendant Hose
3@FT
9013156
361
Strain Relief Wire
1
9013120
363
Hose Fitting
3
TCS135106301
364
Hose Clamp
3
9013155
365
Socket Bolt
1
9091225
366
Washer
1
9012511
350
Under Cover
1
TCS426230470
358
O-Ring
1
TCR131103004
