Page 9
9
Table 2-3 Hook Dimension*
T = Top Hook
B = Bottom Hook
Units = inch
Cap.
(Tons)
Product
Code
Hook
a
b
c
d
e
g
1/2
CF005
T & B
0.8
0.5
0.7
0.5
1.4
1.1
1
CF010
1.0
0.6
0.9
0.6
1.7
1.1
1½
CF015
1.2
0.8
1.0
0.8
1.9
1.3
2
CF020
1.4
0.9
1.2
0.9
2.0
1.4
3
CF030
1.8
1.1
1.5
1.1
2.2
1.7
5
CF050
2.2
1.4
1.9
1.4
2.5
1.8
*Refer to Section 5.7 for inspection dimensions and limits.
2.3
Optional Equipment
2.3.1
Optional Latch Lock Hooks
The Bullard hook has a conventional hook shape with a special, heavy-duty, rotating, spring-
loaded, locking latch. The latch remains locked until it is released by the operator.
The Shur-Loc hook is a special design hook where the latch remains fixed and the hook swings
to unlock. The hook cannot be opened while a load is applied.
Installation of these hooks may change the headroom.
See Section 9.2, Parts List for a complete Latch Lock Hook part listing.
See Table 6-3 for yoke nut torque specifications.
Figure 2-4 Latch Lock Hooks
