42
9.3 Optional Hooks
Figure 9-3 Bullard ® , Shur-Loc ® and Inspection Hooks
Bullard
®
Hooks
Fig. No. Name
Parts
Per
Hoist
1/2 Ton 1 Ton 1 1/2 Ton 2 Ton 3 Ton 5 Ton
1
Bullard ® Top Hook
Complete Set
1 6027601 6027602 6027603 6027606
2 Bullard ® Hook Assembly 1 60160 60162 60164 60169
3 Top Yoke Kit 1 TYKITCB005 TYKITCB010 TYKITCB015
4 Button Head Screw 2 9012612 9012602
5 Flexloc ® Nut** 2 9012613 9012604
6 Warning Tag 1 WTAG6* WTAG6*
7
Bullard ® Bottom Hook
Complete Set
1 6027801 6027802 6027803 6027805 6027807 6027808
8 Bullard ® Hook Assembly 1 60160 60162 60164 60165 60168 60169
9 Bottom Yoke Kit 1 BYKITCB005 BYKITCB010 BYKITCB015
10 Button Head Screw 4 9012612 9012602
11 Flexloc ® Nut** 4 9012613 9012604
12 Warning Tag* 1 WTAG6*
*Hoist with Bullard ® Hook(s) must have WTAG6 and WTAG9 installed. (See page 6 for WTAG9).
**See Table 6- 3 in Owner’s Manual for yoke nut torque specifications.
