Harrington Hoists and Cranes CF Hand Chain Hoist - Manual (Page 43)

43
9.3 Optional Hooks
Shur-Loc
®
Hooks
Fig. No. Name
Parts
Per
Hoist
1/2 Ton 1 Ton 1 1/2 Ton 2 Ton 3 Ton 5 Ton
1
Shur-Loc ® Top Hook
Complete Set
1 6030201 6030202 6030203
2
Shur-Loc ® Hook
Assembly
1 60140 60142 60144
3 Top Yoke Kit 1 TYKITCB005 TYKITCB010 TYKITCB015
4 Button Head Screw 2 9012612 9012602
5 Flexloc ® Nut** 2 9012613 9012604
6 Warning Tag 1 WTAG6*
7
Shur-Loc ® Bottom Hook
Complete Set
1 6030101 6030102 6030103 6030105 6030107
8
Shur-Loc ® Hook
Assembly
1 60140 60142 60144 60145 60148
9 Bottom Yoke Kit 1 BYKITCB005 BYKITCB010 BYKITCB015
10 Button Head Screw 4 9012612 9012602
11 Flexloc ® Nut** 4 9012613 9012604
12 Warning Tag 1 WTAG6*
*Hoist with Shur-Loc ® Hook(s) must have WTAG6 and WTAG9 installed. (See page 6 for WTAG9).
**See Table 6- 3 in Owner’s Manual for yoke nut torque specifications.
Inspection Hooks
Fig. No. Name
Parts
Per
Hoist
1/2 Ton 1 Ton 1 1/2 Ton 2 Ton 3 Ton 5 Ton
1
Top Hook Complete
Set
1 M3001A005IK M3001A010IK M3001A015IK
2 Hook W/Latch & Yoke 1 M3001A005IH M3001A010IH M3001A015IH
3 Button Head Screw 2 9012612 9012602
4 Flexloc ® Nut* 2 9012613 9012604
6
Bottom Hook Complete
Set
1 M3021A005IK M3021A010IK M3021A015IK
7 Hook W/Latch & Yoke 1 M3021A005IH M3021A010IH M3021A015IH
8 Button Head Screw 2 9012612 9012602
9 Flexloc ® Nut* 2 9012613 9012604
*See Table 6- 3 in Owner’s Manual for yoke nut torque specifications.
