BackPlane Connections:
The BackPlane connection is through a sixty position double sided edge connector (thirty connections
on each side on .1Ó centers). This normally is plugged into a card cage, but can also be used with an IDS
or other discrete edge connector. We recommend an Insulation Displacement (IDE) connector for the lat-
ter.
The first ten positions are used for the Smart Brick network and RS-422 Serial Port. They are normally
bussed between all of the cards in the card cage (although they can be separated by cutting the lines if
desired).
The next forty positions are used to connect the J6/A signals to the output cabling.
The last ten positions are used to provide power to the BS-ANA. These wires are ganged to provide a
higher current carrying capacity. The pinout of this connector is as follows:
output wire # Edge pin # color wire function
Smart Brick net #2 1 black Smart Brick Network Data/ into BS-ANA
Smart Brick net #1 2 white Smart Brick Network Data into BS-ANA
Smart Brick net #3 3 red Smart Brick Network Clock into BS-ANA
Serial Port #3 4 red TxD + out from BS-ANA
Smart Brick net #4 5 green Smart Brick Network Clock/ into BS-ANA
Serial Port #2 6 black TxD - out from BS-ANA
Smart Brick net #5 7 yellow Smart Brick Network Strobe into BS-ANA
Serial Port #5 8 yellow Rx + into BS-ANA
Smart Brick net #6 9 blue Smart Brick Network Strobe into BS-ANA
Serial Port #4 10 green Rx -into BS-ANA
J6/A #1 11 brown circuit ground
J6/A #2 12 red + unregulated power output (protected to 1 amp)
J6/A #3 13 orange Output 15 (0Fh) Positive Analog Output
J6/A #4 14 yellow Output 15 (0Fh) Negative Reference
J6/A #5 15 green Output 14 (0Eh) Positive Analog Output
J6/A #6 16 blue Output 14 (0Eh) Negative Reference
J6/A #7 17 violet Output 13 (0Dh) Positive Analog Output
J6/A #8 18 gray Output 13 (0Dh) Negative Reference
J6/A #9 19 white Output 12 (0Ch) Positive Analog Output
J6/A #10 20 black Output 12 (0Ch) Negative Reference
J6/A #11 21 brown circuit ground
J6/A #12 22 red + unregulated power output (protected to 1 amp)
J6/A #13 23 orange Output 11 (0Bh) Positive Analog Output
J6/A #14 24 yellow Output 11 (0Bh) Negative Reference
J6/A #15 25 green Output 10 (0Ah) Positive Analog Output
J6/A #16 26 blue Output 10 (0Ah) Negative Reference
J6/A #17 27 violet Output 9 (09h) Positive Analog Output
J6/A #18 28 gray Output 9 (09h) Negative Reference
J6/A #19 29 white Output 8 (08h) Positive Analog Output
J6/A #20 30 black Output 8 (08h) Negative Reference
J6/A #21 31 brown circuit ground
J6/A #22 32 red + unregulated power output (protected to 1 amp)
J6/A #23 33 orange Output 7 (07h) Positive Analog Output
J6/A #24 34 yellow Output 7 (07h) Negative Reference
J6/A #25 35 green Output 6 (06h) Positive Analog Output
J6/A #26 36 blue Output 6 (06h) Negative Reference
J6/A #27 37 violet Output 5 (05h) Positive Analog Output
J6/A #28 38 gray Output 5 (05h) Negative Reference
J6/A #29 39 white Output 4 (04h) Positive Analog Output
J6/A #30 40 black Output 4 (04h) Negative Reference
