23
Power Macintosh 6360 Installation
Remove Level 2 Cache Card
If installed, remove the Level 2 cache card located next to two larger
slots that contain the DRAM (memory) DIMMs (Figure 5).
Reset CUDA Switch
Reset the CUDA switch on the logic board (Figure 6). It is located
directly next to the L2 Cache Slot. Resetting this switch ensures that a
processor upgrade card you installed into your computer is recognized
at the next startup.
Figure 5: Remove Level 2 cache card
Figure 6: Reset CUDA switch
L2 Cache Slot
DRAM DIMMs
L2 Cache Slot
Level 2 cache card
CUDA switch
