AUX - SSCL1500V800A5KVB
Power Semiconductor Half-Bridge Module
Main
SGTO
Limiting Inductor
Circuit
Breaker
Notes
1.) Measurements made with a 10 Ohm shorting resistor connected between the gate and
cathode.
2.) Additional testing to customer requirement is available
3. ) Production testing is limited to 2KV prior to encapsulation.
4.) Characterization accomplished using R
gk
=10 ohms.
Application Note: Solid State Current Limiter
CAO 05/28/09
SGTO
switch
i
LINE
Varistor
Line
reactance
Auxiliary SGTO
switch
Commutation
Capacitor Commutation
Inductor
Breaker
