M O S A I C T I L E S A N D G R I D
The grid and tile construction allows the highest
flexibility in regard to overall sizing, modification of
display layout and addition or omission of indicators,
control devices, and equipment without the use of
special tools or training. The tile assembly is custom-
ized to the specific requirement of an application in
multiples of a single tile size increment. The grid is
supported from the peripheral framework and cross
beam structure for maximum stability. The graphic
assembly is installed through a single panel cutout of
the control panel and secured with clamps provided.
T I L E S A N D G R I D M AT R I X
The high precision 12″ x 12″ (304.80 mm x 304.80 mm)
standard grid is molded from glass-filled nylon 6/6 flame-
retardant 94V-0 material. The grid is cut in 1″ (25.40 mm)
increments and is assembled to meet size
requirements.
The tiles are molded from polycarbonate
flame-retardant 94V-0 material and are self-
extinguishing, highly resistant to ultraviolet
rays, and meet ASTMD648 heat deflection
temperatures of 280° F. The tiles are available
in 1″ x 1″ (25.40 mm x 25.40 mm) and
2″ x 2″ (50.80 mm x 50.80 mm). The two
sizes may be mixed on the same grid, with 2″ x 2″
(50.80 mm x 50.80 mm) tiles suitable for larger graphics.
