UNIVERSAL WALL PLATE
ITEM 09010-1
Maple Chase Company, Downers Grove, IL
INSTRUCTIONS:
1. Determine which holes to use from the chart below.
2. If required, use a punch or screwdriver to remove any plastic "knockout"
from hole.
3. Place the wall plate between the wall and the thermostat, the mount
the thermostat according to the installation instructions provided with
the thermostat.
110-363B
FOR
USE HOLES
• Saverstat 0960 series and 09600
C, G
series programmable thermostats
• Mechanical Thermostat
D, E
• Door Chime
A, H
