Robertshaw SLIMZONE ENVIRONMENTAL MODULE - Manual (Page 11)

STEP DESCRIPTION DURATION
6 Time delay – equalize system 30 seconds
5 Self calibrate – 0 pressure 30 seconds
4 Wait state – Status calibration Instantaneous
3 Fan on – bypass closed, open dampers,
90 seconds
measure system pressure
2 Store operation pressure Instantaneous
1 Read data from module Instantaneous
0 Read data from module Instantaneous
BYPASS SYSTEM SETUP
NOTE: The bypass setup is done by the SZP control module. Refer to section 6 of the
SlimZone Premier Installation and Operation Manual “Start Up and Test” for the startup
sequence.
1. Ensure that all components in the bypass system have been properly installed.
2. At the SZP module, select the Bypass Setup menu.
NOTE: The SZP control module will automatically setup the bypass system. The equipment
for the zone dampers and bypass dampers will be activated accordingly during the
setup sequence. The duration of the setup is approximately 5 minutes.
3. Proceed with the setup. The SZP module will proceed with the following 7 steps:
NOTE: The duration of each setup is approximate. Step 3 may repeat several times; when
