Digital Non-Programmable Thermostat

Installation and User Manual
Model: RS2110 and RS2210 Series

INSTALLATION MANUAL

The information supplied here is for the mounting, wiring and switch
set up for the RS2110 and RS2210 thermostats. For programming and
operating functions, refer to the User Manual section.
Thank you for selecting our wall thermostat. Robertshaw

®

products are

manufactured to high quality standards and are designed to provide
years of service.
The RS2110 and RS2210 thermostats work with the following climate
control configurations:
• Heat Pump (No Auxiliary Heat)
• Heat Pump (With Auxiliary/Emergency Heat)
• Standard Heat and Cooling Systems
• One Stage Heat/Cool - RS2110
• Two Stage Heat, One Stage Cool - RS2210
• Standard Heat Only Systems
• Millivolt Heat Only Systems - Floor or Wall Furnaces
• Standard Central Air Conditioning
• Gas or Oil Heat
• Electric Furnace
• Hydronic (Hot Water) Zone Heat-2 Wires
• Not to be Used With Split Transformer Systems
The RS2110 and RS2210 thermostats will NOT work with 3-Wire
Hydronic (Hot Water) Zone Heat 110/220 Volts. This thermostat
operates on 24 VAC power or battery power.

IMPORTANT SAFETY INFORMATION

WARNING:

Electrical Shock Hazard
Turn off power at the main power source by unscrewing
the fuse or switching the circuit breaker to the

OFF

position before installing, removing or cleaning this
thermostat.

Fire and Electrical Shock Hazard
This device should be installed by a qualified service
technician with due regard for safety as improper
installation could result in a fire and electrical shock
hazard.

Fire and Electrical Shock Hazard
This is a 24 VAC low-voltage thermostat. Do not install on
voltages higher than 30 VAC.

• Do not switch system to

COOL if the temperature is below 50ºF

(10ºC). This can damage your cooling system and may cause
personal injury.

• Do not short (jumper) across terminals on the gas valve or at the

system control to test installation. This will damage the thermostat
and void the warranty.

• Do not connect ground to any terminal in this unit.
• All wiring must conform to local and national building and

electrical codes and ordinances.

• Use this thermostat only as described in this manual.
CAUTION:
• Read all the information in this manual before installing this

thermostat.

• This thermostat is equipped with automatic compressor protection

to prevent damage due to short cycling or extended power
outages. The short cycle protection provides a 4 minute delay
between heating or cooling cycles to prevent the compressor from
being damaged.

• The batteries must be replaced at least every 18-24 months to

assure proper operation. The thermostat will display a flashing low
battery when it is time to replace the batteries. The manufacturer
recommends inserting fresh batteries before leaving for an
extended period.

Recycling Thermostat

This thermostat does not contain mercury. However, if this thermostat
is replacing a thermostat that contains mercury in a sealed tube, do
not place your old thermostat in the garbage. Contact your local waste
management authority for instructions regarding proper disposal of
the thermostat. If you have any questions, call Robertshaw technical
support at 1-800-445-8299.

MOUNTING

What you need:
This thermostat includes two #8 slotted screws and two wall anchors
for mounting. To install your thermostat, you should have the following
tools and materials.

• Slotted Screwdriver(s)

• Small Phillips Screwdriver

• Hammer

• Electric Drill and 3/16" Bit

• Two 1.5V (AA) Alkaline

Batteries (included)

Replacing Existing Thermostat

WARNING:

Electrical Shock Hazard
Turn off power at the main power source by unscrewing
the fuse or switching the circuit breaker to the

OFF

position before installing, removing or cleaning this
thermostat.

IMPORTANT:
• Before removing wires from old thermostat, label each wire with

the terminal designation it was removed from.

• Do not install on voltages greater than 30 VAC.
• Do not install on outside walls or in direct sunlight.
1. Shut off electricity at the main fuse box until installation is

complete. Ensure that electrical power is disconnected.

2. Remove old thermostat: A standard heat/cool thermostat

consists of three basic parts:
a. The cover - may be either a snap-on or hinge type.
b. The base - remove by loosening all screws.
c. The switching subbase or adapter plate - remove by

unscrewing the mounting screws that hold it on the wall.

3. Remove the front cover of the old thermostat. With wires still

attached, remove wallplate from the wall. If the old thermostat
has a wall mounting plate, remove the thermostat and the wall
mounting plate as an assembly.

4. Identify each wire attached to the old thermostat.
5. Label each wire to identify which terminal it was connected to.
6. Disconnect the wires from the old thermostat one at a time. DO

NOT LET WIRES FALL BACK INTO THE WALL.

7. Install new thermostat using the following procedures.
WARNING: Do not use on circuits exceeding specified voltage. Higher

voltage will damage the control and could cause an
electrical shock or fire hazard. Do not short out terminals
on gas valve or primary control to test.
Incorrect wiring will damage the thermostat and could
cause personal injury and/or property damage.

Attach Thermostat Base to Wall

1. Remove the packing material from the thermostat. Push in on

the tab at the bottom. Gently pull the cover straight off the base.
Forcing or prying on the thermostat will cause damage to the
unit.

CAUTION: Be certain all power is off to the system.
2. Pull the wires through the hole in the base. Connect wires

beneath terminal screws on base using the table under terminal
connections.

3. Place base over the hole in wall and mark mounting hole

locations on wall using the base as a template.

4. Move the base out of the way. Drill mounting holes.
5. Fasten base loosely to wall, using two mounting screws. Place a

level against bottom of base, adjust until level, and then tighten
screws. Leveling is for appearance only and will not affect
thermostat operation. If you are using existing mounting holes,
or if holes drilled are too large and do not allow you to tighten
base snugly, use plastic screw anchors to secure the subbase.

6. Push excess wire into wall and plug hole with a fire resistant

material (such as fiberglass insulation) to prevent drafts from
affecting thermostat operation.

Mounting Holes

Terminals

Figure 1 Thermostat Base

System Switch Selection

STD

HP

GAS

ELEC

Heat Pump or Non-Heat Pump (RS2110C only)

Gas or Electric

Figure 2 Electric/Gas Switch (Fan Option)

The RS2110 thermostat is configured from the factory to operate a
heat/cool, fossil fuel (gas, oil, etc.), forced air system. It is configured
correctly for any system that DOES NOT require the thermostat to
energize the fan on a call for heat.
The RS2210 is configured at the factory to operate an electric heat or
heat-pump system that requires the thermostat to turn on the fan on
a call for heat. Locate the

ELEC/GAS switch on the back of the ther-

mostat (see “Figure 2 Electric/Gas Switch (Fan Option)”) and switch it
to the

ELEC position. This will allow the thermostat to energize the fan

immediately on a call for heat.
Press the

RESET button to accept a change in the switch option.

If your system is not a heat pump system, refer to the Configuration
section in this manual. The RS2210 thermostat must be changed to a
STD type system.
If you are unsure if the heating/cooling system requires the thermo-
stat to control the fan, contact a qualified heating and air conditioning
service person.

When the thermostat is configured for heat pump, the thermostat will
always power the circulator fan on a call for heat in the Heat mode.
The

ELEC/GAS switch for the 2 stage RS2210 model must be set to

match the type of auxiliary heat your system uses for proper operation
in the Emergency mode.
All wiring diagrams are for typical systems only. Refer to equipment
manufacturer’s instructions for specific system wiring information.

Thermostat Terminals

Terminal

Equipment to

Connect

Description

One Stage Model RS2110

C

24 VAC common

connection

For input of 24 VAC common side of
transformer. If 24 VAC is not present
the thermostat is powered by batter-
ies only and THE SYSTEM WILL NOT
OPERATE

.

R

24 VAC + con-

nection

For input of 24 VAC hot side of
transformer runs heating and cooling
system.

O

Energizes for heat pump cool revers-
ing valve.

B

Energizes for heat pump heat revers-
ing valve.

G

Indoor fan con-

nection

Energizes with Y1 and Y2.
Energizes with W1 and W2 if the

ELEC/GAS switch is set to electric.
Energizes when fan is switched to

On.

Y1*

First stage

compressor con-

nection

Energizes on a call for first stage of
cooling.
Energizes on a call for first stage of
heating when configured as a

HP.

E/W1*

First stage heat/
emergency heat

connection

Energizes on a call for first stage
of heating when configured as a
Non-Heat Pump. For Heat Pump
configuration, will energize for emer-
gency heat.

*This thermostat can be used as a heat only or cool only thermostat.
Therefore, it is not always necessary to use both W1 and Y1.

Terminal

Equipment to

Connect

Description

Two Stage Model RS2210 (Additional Terminals)

W2

Second stage

heat connection

Energizes on a call for second stage
heating.

L

24 VAC com-
pressor fault

output

For input of fault signal from a
compressor.

Replace the cover by inserting the bottom tab on the thermostat body
into the slot at the bottom of the wallplate. Move the cover to meet
the top of the wallplate. Press the top of the body to snap it into the
wallplate.
CAUTION: Do not force the thermostat body onto the wallplate. Termi-

nal pins inside the thermostat may become damaged.

WIRING DIAGRAMS
Heat Pump Terminal Outputs

Refer to the equipment manufacturer’s instructions for specific system
wiring information. You can configure the thermostat for use with a
Heat Pump Type 1, single stage compressor system. This thermostat
is designed to operate a single transformer system. If you have a two
transformer system, cut and tape off one transformer. If transformer
safety circuits are in only one of the systems, remove the transformer
of the system with no safety circuits. If required, replace the remain-
ing transformer with a 75 VA Class II transformer. After disconnecting
one transformer, the two commons must be jumpered together.
Use the terminal output information below to help you wire the ther-
mostat properly for your system.

Single Stage Heat and Cool: RS2110

A. Typical wiring diagram for single transformer standard system.

System selector switch must be set to

STD.

NOTE: “Battery Operation Only” if 24 VAC common not present, other-

wise “Battery Backup”.

C R O B G Y1 W1

24 VAC Common

(Battery Operation

Only if not present)

24 VAC

Supply

Fan Relay

Compressor

Contactor

First Stage

Heat

B. Typical wiring diagram for single transformer heat pump system.

System selector switch must be set to

HP.

NOTE: “Battery Operation Only” if 24 VAC common not present, other-

wise “Battery Backup”.

C R O B G Y1 W1

24 VAC

Common

(Battery

Operation

Only if not

present)

24 VAC

Supply

Fan Relay

Compressor

Contactor

Cool Active

Reversing

Valve

Heat Active

Reversing

Valve

Two Stage Heat Single Stage Cool: RS2210

C. Wiring diagram for single transformer standard system. System

selector in configuration menu must be set to

STD2 or STD1

(single stage only).

NOTE: “Battery Operation Only” if 24 VAC common not present, other-

wise “Battery Backup”.

C R O B G Y1 E/W1

24 VAC

Common

(Battery

Operation

Only if not

present)

24 VAC

Supply

Fan Relay

Compressor

Contactor

L

W2

First Stage

Heat

Second Stage

Heat (if STD2

selected)

D. Wiring diagram for single transformer heat pump system. System

selector in configuration menu must be set to

HP.

NOTE: “Battery Operation Only” if 24 VAC common not present, other-

wise “Battery Backup”.

C R O B G Y1 E/W1

24 VAC

Common

(Battery

Operation

Only if not

present)

24 VAC

Supply

Fan Relay

Compressor

Contactor

Cool Active

Reversing

Valve

Heat Active

Reversing

Valve

L

W2

Compressor

Fault Output

(24 VAC) from

Heat Pump

Emergency

Heat

Second

Stage or

Auxiliary Heat

E. Typical wiring diagram for single transformer heat pump systems.

24 VAC

Supply

R

Y1

Compressor

Contactor

O

Reversing

Valve

Energized

in Cool

Mode

B

Reversing

Valve

Energized in

Heat, Off,

Emergency

Mode

24 VAC

120

VAC

Neutral

Hot

Transformer (Class II Current Limited)

C

24 VAC

Common

(Battery

Operation

Only if not

present)

System

Monitor

Switch

L

=

Compressor

Fault Output

(24 VAC) from

Heat Pump

Auxiliary

Heat Relay

Emergency

Heat Relay

G

Fan Relay

E/W1 W2

F. Typical wiring diagram for single transformer heat pump only.

R

G

Fan Relay

Y1

O

Reversing

Valve Ener-

gized in Cool

Mode

B

Reversing Valve

Energized in

Heat, Off,

Emergency

Mode

24 VAC

120

VAC

Neutral

Hot

Transformer (Class II Current Limited)

C

Compressor

Contactor

Stage 1

Emergency

Heat

Heat Relay

Stage 2

Compressor

Fault Output

(24 VAC) from

Heat Pump

E/W1 W2 L

Battery Compartment - Open with finger from sides. Install two AA
1.5V batteries.
Reset Button - Press to return to factory default.
Door Latch - Press gently on door to open/close.
System Switch - Select Cool/Off/Heat.
Fan Switch - Set for continuous or automatic fan operation.
IMPORTANT: Please read the entire User Manual section before set-

ting your thermostat.

DISPLAY MAP

The thermostat display will show information that is being used during
operation or programming. This illustration shows all of the display’s
possibilities with an explanation.

1

2
3

4

5

6

Figure 5

1. Used with setpoint.
2. Used for service reminders (e.g. CHECK HP).
3. Used for current setpoint and some configuration data.
4. HVAC mode and status. Icons blink when active. A is for Auto, 2

is for second stage and E is for emergency.

5. Low battery indicator.
6. Used for ambient temperature and configuration data (e.g. first

stage differential, F or C, etc.).

COMPRESSOR PROTECTION

The thermostat provides a 4 minute delay after shutting off the
heating or cooling system before it can be restarted. This feature will
prevent damage to your compressor caused by rapid cycling. Note
that this delay also applies to the heating system control. It does not
provide a delay when there are power outages.

TEMPERATURE RANGE

This thermostat can be set between 45ºF and 90ºF (7ºC and 32ºC).
However, it will display room temperatures from 30ºF to 99ºF (0ºC and
37ºC).
NOTE: If the thermostat measures a temperature over 99ºF (37ºC), HI

will be displayed on the LCD. If the temperature is below 32ºF
(0ºC), LO will be displayed on the LCD.

AUTO CUT-OFF

Your thermostat will automatically shut down in Heat mode if the room
temperature rises above 95ºF (35ºC). It will shut down in Cool mode if
the room temperature drops below 45ºF (7ºC).
Note that if your system has malfunctioned and no longer responds to
thermostat controls, the Auto Cut-Off will not work.

EMERGENCY HEAT - RS2210 WITH HEAT PUMP

Consult with your installer to determine if your system is a heat pump
with an emergency heat system installed. If you have an emergency
heat system you can activate it in

HEAT mode by pressing the UP and

DOWN arrows together. The display will show an E by the flame icon
when the thermostat is in system

HEAT mode.

The main heating system will not receive a call to turn on. This will
allow maintenance to take place on the main heat system. To turn off
the emergency system, press the

UP and DOWN arrows together. The

E will no longer be displayed.

POWER FAILURE

Whenever the main power is interrupted or fails, the back-up battery
power will maintain the current settings. The heating and cooling
systems will not function. In the event of a power outage and dead
batteries, the settings will revert to default settings when power is
resumed. You must reprogram your settings.

FILTER MONITOR

The thermostat counts the number of hours your system’s filter has
been in use. To maximize your system’s performance and energy
efficiency, change or clean your filter regularly. When the total system
run time for heat and cool reaches 400 hours, the filter change indica-
tor (

Check FLtr) will flash as a reminder to check your system’s filter.

Press and hold the

UP and DOWN arrows together until Check FLtr

no longer displays. This will reset the filter monitor to zero.

BATTERY WARNING

+

- +

-

Figure 6

When the batteries become weak, a flashing battery symbol will
appear on the screen. When this symbol occurs, install two new AA
batteries. You have approximately one minute to change the batteries
and keep the thermostat’s program settings. Once the batteries have
become too weak to ensure proper operation, your system will be
turned off, and the display will be blank if battery powered.
CAUTION: When the battery symbol flashes the batteries are weak. If

they are not replaced the display will fade. When the bat-
teries are dead the display will be blank. There will be no
temperature control and settings are not saved.

NOTE: If you plan to be away from the premises over 30 days, we

recommend that you replace the old batteries with new alka-
line batteries prior to leaving.

CONFIGURATION

The

RESET button can be pressed with a paper clip to reset the

thermostat back to the factory defaults as shown in the Configuration
Menu Options table.
The Configuration Menu allows you to set certain thermostat operating
characteristics for your system or personal requirements. Set System
switch to

OFF, then simultaneously press the UP and DOWN arrows

for three seconds to enter the Configuration Menu which summarizes
the options available. The display will show the first item in the Con-
figuration Menu Options table. An explanation of each option is listed
after the table. Press the

DOWN arrow to change to the next menu

item. To change the setting, press the

UP arrow. When the maximum

setting is reached, the selections will return to the lowest selection. To
exit the menu and return to the program operation, press the

DOWN

arrow until the main display appears. If no buttons are pressed within
fifteen seconds, the thermostat will revert to normal operation.

Configuration Menu Options

Item

Default

Temperature Scale F/C

F

First Stage Differential

1°F (0.5°C)

RS2210 only - Second Stage Differential

2°F (1.1°C)

Off Set

0

RS2210 only - DLY 2

20

RS2210 only - System Type

HP

Temperature Scale - Select Fahrenheit or Celsius.
First Stage Differential - When the room temperature approaches the
set temperature the differential is the amount of overshoot allowed
before the thermostat calls for heating/cooling.
Second Stage Differential - Used for RS2210 only, same as First Stage
Differential but controls a second stage system.
Offset - Use this to change ambient temperature readings up or down.
DLY2 - Used for RS2210 only, is the second stage delay time.
HP - Used for selecting the system type on the RS2210. Select

HP for

heat pump. Select

STD1 for one stage heating non-heat pump. Select

STD2 for two stage heating non-heat pump.
Familiarize yourself with these manual settings, so that you can easily
modify your settings as your comfort needs change. The example
below demonstrates the manual settings method.
NOTE: The temperature can be set in increments of 1ºF (1ºC).The heat

setpoint cannot be set higher than the cool setpoint, and the
cool setpoint cannot be set lower than the heat setpoint. If the
system selector is in Heat mode, the heat operating mode will
be set. After 15 seconds without a button press, the thermo-
stat will return to Normal Display mode.

Changing Settings

Start with a normal running display.
1. Select Heating with the system switch.
2. Use the

UP and DOWN arrows to select the temperature for

heating.

3. Switch between

HEAT and COOL. Repeat step 2 to select the

temperature for cooling.

OPERATION
System Selector Switch

system

cool off heat

The System Selector switch on the front of the
thermostat determines the operating mode of the
thermostat. You may select

COOL, OFF, or HEAT.

NOTE: Anytime you install or remove the thermostat

from the wallplate, slide the System Selector to the

OFF posi-

tion to prevent the possibility of a rapid system on-off.

Fan Switch

fan

on

auto

The Fan switch should normally be set in the

AUTO

position. The fan will be turned on along with normal
operation of your system. In a normal gas or oil
furnace, the fan will be turned on by your furnace
after its warm-up delay. For electric heat, air

conditioning, and heat pump operation, the fan will turn on with the
system. To run the fan continuously, slide the Fan switch to the
ON position.

TROUBLESHOOTING

Problem

Solution

Scrambled or double
display (numbers over
numbers).

Remove clear mylar sticker.

No display.

Check connections and batteries.
Press Reset once with a small pin and
hold for two seconds then reprogram.

Entire display dims.

Replace batteries.

Auto/Fan does not turn
On.

There may be as much as four minute
delay before the heat or cool system
turns on. Wait and check. (Compressor
protection delay).
Check your circuit breakers and switches
to ensure there is power to the system.
Replace batteries.
Make sure your furnace blower door is
closed properly.
Check the position of the furnace or Heat
Pump selector switches.

Erratic display.

Press

RESET once with a small pin and

hold for two seconds then reprogram.

Thermostat reads E1.

Temperature sensor defective. Replace
unit.

Thermostat reads E2.

System switch in wrong position. Move
system switch to correct position.

If you experience any other problems, contact Technical Support at:
www.invensyscontrols.com or (800) 445-8299.

INSTALL BATTERIES

The thermostat will operate using 24 VAC or two AA batteries. When the
two AA batteries are installed the thermostat will continue to run if the
24 VAC fails.
To open the door to the battery compartment, gently pull down on the
sides. Install two AA batteries following the polarity as shown inside the
compartment. Close the door.

+

- +

-

Figure 3

When the batteries are low the thermostat will enter a low battery mode.
Low battery mode has two levels:

• Level 1 - The low battery icon will be

displayed. The thermostat will continue to
operate. Replace the batteries as soon as
possible.

• Level 2 - The low battery icon will flash. If 24

VAC is present the thermostat will continue
to operate if the batteries are discharged
or removed. If 24 VAC is not present the
thermostat is powered by batteries only and
THE SYSTEM WILL NOT OPERATE. Replace
batteries immediately.

Replace batteries if leaving thermostat unattended for more than
30 days.

CHECK THERMOSTAT OPERATION
Fan Operation

If your system does not have a G terminal connection, skip to Heating
System.
1. Turn on power to system.
2. Move Fan switch to

ON position. The blower should begin to

operate.

3. Move Fan switch to

AUTO position. The blower should stop

immediately.

Heating System

1. Move System switch to

HEAT mode. If the heating system has a

standing pilot, be sure to light it.

2. Press the

UP arrow to adjust thermostat setting to 1˚F/1˚C above

room temperature. The heating system should begin to operate.
The display should show the flame icon in motion.

3. For a RS2210 system, adjust temperature setting to 3˚F/3˚C

above room temperature. If your system configuration is set for
auxiliary heat, the auxiliary heat system should begin to operate.
A 2 will appear by the flame icon.

4. Press the

DOWN arrow to adjust the thermostat below room

temperature. The heating system should stop operating.

Cooling System

1. Move System switch to select the

COOL mode.

2. Press the

DOWN arrow to adjust thermostat setting below room

temperature. The blower should come on immediately on high
speed, followed by cold air circulation. The display should show
the snowflake icon pulsing.

3. Press the

UP arrow to adjust the temperature setting above

room temperature. The cooling system should stop operating.

If these tests are not successful, remove the thermostat body and
check for bent pins. Check all wiring connections.
If these tests are successful the thermostat is ready to operate using
the factory defaults. To change the configuration settings, refer to
Configuration in the User Manual section.
Installation of the thermostat is now complete. Remove the protec-
tive mylar over the screen and check that fresh batteries are properly
installed. Close all doors.

USER MANUAL

Thank you for selecting our wall thermostat. Robertshaw

®

products

are manufactured to high quality standards and are designed to
provide years of service.

FEATURES AND BENEFITS

• Multi-Stage 2 Heat/1 Cool - RS2210 only. Operates on both

multi-stage gas/electric furnaces and heat pumps.

• New Improved Display makes viewing and setting the temperature

easier.

• Adjustable Temperature Differential maintains optimal customer

comfort.

• Worry-Free Memory Retention - RS2210 only. Maintains set point

and programmed parameters, even during power outages.

• Filter Monitor provides notice when filters need changing.
• Automatic Compressor Short Cycle Protection reduces wear and

tear of HVAC equipment with this system safeguard.

• O and B Terminals provides greater system flexibility.
• Zone System Compatible acts as a sensor within the system.
• Quick Wire Terminal Block uses sturdy wire clamps for fast and

easy installation - no wrapping around screws.

This section will describe the features and how to set up the RS2110
and RS2210 thermostats. Installation is described in detail in the
Installation Manual section.

+

- +

-

LCD Display

Down and

Up Arrows

Battery

Compartment

Door Latch

System Switch

Fan Switch

Reset Button

Figure 4

LCD Display - Shows Day, Temperature and other feature information.
Down and Up Arrows - Used to enter and navigate the configuration
menu and change the temperature settings.

352-00021-001 Rev B

191 E. North Avenue
Carol Stream, Illinois 60188 USA
www.invensyscontrols.com
©2012 Invensys Controls 7/12

This manual is related to the following products:
