9505

ECONOMY

NON-PROGRAMMABLE

THERMOSTAT

GAS

ELECTRIC

OIL

MILLIVOLT

Maple Chase

09505

Robertshaw

300-211

Honeywell, Inc.*

T87

* Verify specific application requirements before substitution.

1 Heat

Terminal Designations

THE ROBERTSHAW

9505

REPLACES:

24 VAC

Transformer

Fan

Relay

Heating

Relay

Shipping Information

Indiv. Ctn. Dim.:

6.75" x 4.375" x 1.625"

Master Ctn. Qty.:

Master Ctn. Dim.:

9.25" x 5.625" x 7.625"

Master Ctn. Cu. Ft.: .23
Master Ctn. Wt.:

4.0 lbs.

Max. Pallet Qty.:

1170

Max. Pallet Dim.:

40" x 48" x 48"

Max. Pallet Cu. Ft.: 53.33
Max. Pallet Wt.:

835 lbs.

Other Single-Stage Heat
Thermostats

986-1: Mechanical
9204: Mercury-Free Deluxe Mechanical
9205: Mercury-Free Deluxe Mechanical, Millivolt

Specifications

Electrical rating: 24 Volt AC (18-30 VAC) and
millivolt (250mV-750mV)
1 amp maximum load per terminal
2 amp total maximum load (all terminals combined)
Temperature control range: 45˚- 90˚F (7˚- 32˚C)
Accuracy: +/-1˚F (+/-.5˚C)
DC power: 3.0 Volt
(2 “AA” alkaline batteries included)
System configurations: 2-3 wire gas, oil, or electric
heating systems
Terminations: R, W, G
