Page 39
CP-97-02.5
9040 Classic for REA & M90 Systems - Parts Identification
3 6
3 6
3 6
3 6
3 6
1
PC Board and Heat Sink Assembly:
PC Board and Heat Sink Assembly:
PC Board and Heat Sink Assembly:
PC Board and Heat Sink Assembly:
PC Board and Heat Sink Assembly:
76892-10
For 76447-10X, REA-IV Applicator (70404)
76892-12
For 76447-12X, REA-III Applicator (70929, 72316)
76892-13
For 76447-13X, REA-III Automatic (70393)
76892-15
For 76447-14X, M90 Classic Applicator (77132)
2
High Voltage Multiplier (Oil-Filled):
High Voltage Multiplier (Oil-Filled):
High Voltage Multiplier (Oil-Filled):
High Voltage Multiplier (Oil-Filled):
High Voltage Multiplier (Oil-Filled):
76304-02
For 76447-10X, 65kV
76304-07
For 76447-14X, 85kV
76304-01
For 76447-12X and 76447-13X, 90kV
3
76434-01
ON/OFF Switch
1SW
4
70556-03
High Voltage Adjust Potentiometer
1POT
5
76436-91
Kilovolt (kV) Meter
1M
6
76436-92
Microamp (μA) Meter
2M
7
Air Flow Switch Assembly:
Air Flow Switch Assembly:
Air Flow Switch Assembly:
Air Flow Switch Assembly:
Air Flow Switch Assembly:
1FS
13742-01
For 76447-10X and 76447-12X
13742-02
For 76447-14X
25766-106
Pressure Switch for 76447-13X
1PS, 2PS
8
75337-05
Power Supply, 18 VDC
1SUP
9
LSME0082-04
Fuse, PC Board, Slow Blow, 4 Amp
F2
10
Fuse, Front Panel:
Fuse, Front Panel:
Fuse, Front Panel:
Fuse, Front Panel:
Fuse, Front Panel:
72771-06
Slow Blow, 1 Amp, 110-120 VAC Input
1FU
72771-01
Slow Blow, 0.5 Amp, 220-240 VAC Input
1FU
11
6262-00
AC Line Cord
12
70539-00
Ground Wire Assembly
13
76455-02
LED Display Board
14
Overload Indicator and Reset Switch Assembly:
Overload Indicator and Reset Switch Assembly:
Overload Indicator and Reset Switch Assembly:
Overload Indicator and Reset Switch Assembly:
Overload Indicator and Reset Switch Assembly:
76442-01
Reset Switch, Normally Closed
76441-00
Lens, Yellow
76443-01
Bulb
15
5627-00
Rubber Feet
Item #
Item #
Item #
Item #
Item #
9040 CLASSIC for REA
9040 CLASSIC for REA
9040 CLASSIC for REA
9040 CLASSIC for REA
9040 CLASSIC for REA & M90 - P
& M90 - P
& M90 - P
& M90 - P
& M90 - PAR
AR
AR
AR
ARTS LIST
TS LIST
TS LIST
TS LIST
TS LIST (Figure 1
(Figure 1
(Figure 1
(Figure 1
(Figure 11)
1)
1)
1)
1)
Part #
Part #
Part #
Part #
Part #
Description
Description
Description
Description
Description
Notation
Notation
Notation
Notation
Notation
