MANUAL CHANGE SUMMARY
This manual was published to supercede Service
Manual LN-9238-02.2, Serial Node Adapter/Serial
Node Adapter + to make the following changes:
1. Revise Figure 4: RIO Discrete Inputs in the
"Installation" section, page 7.
2. Revised "Serial Bus Connection to Other
Motherboards" in the "Installation" section, page 8.
3. Updated "Table 1 - Serial Node Adapter +
LECU4012-00, PLC I/O MicroPak Mode, Discrete
Output Configuration" in the "Operation" section,
page 13.
4. Updated "Table 3 0- Node Adapter + LECU4012-
00, PLC I/O - Flex Mode (Dipswitch SW2-1
and SW2-5 On, Block Transfer Reads" in the
"Operation" section, page 17.
5. Updated "Table 3 - Node Adapter + LECU-
4012-00, PLC I/O - Flex Mode (Dipswitch SW2-1
and SW2-5 On), Digital Modules, No AirTronic
Modules, Block Transfer Read 8AirTronic Module
Word Definition" in the "Operation" section, page 21.
6. Updated "Table 3 - Node Adapter + LECU4012-
00, PLC I/) - Flex Mode (Dipswitch SW2-1 and
SW2-5 On), airTronic Modules, No Digital Modules,
Discrete Output Configuration" in the "Operation
" section, page 23.
7. Revised "Module Identification Numbers" chart
in the "Operation" section, page 29.
8. Revised "BTW's Used for Configuartion Words"
chart in the "Operation" section, page 30.
9. Revised "BTW's Used for Configuartion Words"
chart in the "Operation" section, page 32.
10. Revised "Serial Node Adapter + LED Indicators
in the "Maintenance" section, page 33.
11. Revised "Flexible 1/4 Rack Motherboard
System Part Numbers" in the Operation" section,
page 34.
Serial Node Adapter/Serial Node Adapter + - Manual Change
Ransburg
38 LN-9238-02.3
