Table 3 - Node Adapter + LECU4012-00
PLC I/O - Flex Mode (Dipswitch SW2-1 and SW2-5 On) (Cont.)
BIT
STATUS
00-07
08
09
10
11
12
13
14
15
Bearing Air (8-Bit)
Overspeed
Underspeed
Loss of Feedback
Invalid Data Input
Low Bearing Air
Bell Running
Out of Tolerance
(Not Used)
BLOCK TRANSFER READ
ATOMIZER MODULE WORD
DEFINITION
BLOCK TRANSFER READ
MICROPAK WORD
DEFINITION
BIT
STATUS
00
01
02
03
04
05
06
07
08
09
10
11
12
13-15
High Voltage In Reset
High Voltage Ready
High Voltage On
Di/dt Fault
High Voltage Overload
Feedback Fault
Seqence Mode
Local Mode
Fluid Trigger On
Air Trigger On
Di/dt Enabled
KV Out of Tolerance
Low Output Current
(Not Used)
Serial Node Adapter/Serial Node Adapter + - Operation
Ransburg
22
LN-9238-02.3
