Page 14

RMA-303 Direct Charge - Introduction

LN-9266-11.3

SPECIFICATIONS - Electrical / Mechanical

Electrical

Power Supply Type:

MicroPak

Charging Method:

Direct

Output Voltage:

0-100 kV Variable

Output Current:

125 µA

Turbine Speed Control:

Atomizer Module

Part Spray ability:

Determine spray ability of part to be coated using Test Equip -

ment (76652) (Paint Conductivity Meter)

Mechanical

Length:

. (See RMA-303 Tool Point, Center of Gravity, and Envelope

Dimen sions (Single and Dual Flex) figure in the “Introduction”
section.)

Diameter:

(See RMA-303 Tool Point, Center of Gravity, and Envelope

Dimen sions (Single and Dual Flex) figure in the “Introduction”
section.)

Approximate Weight

Atomizer Only: 17.3 lbs. (7.83 Kg) max.

Total Payload with Robot
Plate & Adapter:

20.1 lbs. (9.12 Kg) max.

Turbine Type:

Air Bearing Impulse Drive

Turbine Air Supply:

Variable (See “Pressure Flow Data Charts” in the

“Introduction” section.)

Maximum/Minimum
Turbine Speed:

Continuous 70K rpm max./20K rpm min.

Maximum Angular Velocity
for Turbine (Robot Motion):

250

/sec.

Tubing Bundle Max.
Rotation:

450

in Either Direction

Bearing Air Supply
at the Applicator:

90 psig (±10 psi)

Nominal):

(621 kPa ±69 kPa) 2.9 SCFM (82 slpm)

Shaping Air #1 (SAI) Supply:

Variable (See “Pressure Flow Data Charts” in the

“Introduction” section.)
