PRODUCT OVERVIEW
Fig. 1 shows the controls, indicators and physical features of
the BF10’s transmitter and receiver. Familiarize yourself with
their names and functions before moving on to the Operating
Instructions
Fig. 1. The controls, indicators and
physical features of the BF10
A. Function switch
B. Socket test indicator lights
C. Flashlight (on underside)
D. Tip with sensor
E. Yellow “low battery” LED
F. Green “breaker found” LED
G. Red “breaker not found” LED
H. Power on/off button
I. Flashlight on/off button
J. Battery compartment
(on back)
6
A
B
D
C
E
F
G
H
I
J
Fig. 1
