Fairbanks IM 6000 Series In-Motion Scale System with FB3000 - Manual (Page 23)

50792 23 05/05 Issue #1
A. Replacement Parts
Item Part Number Description
1 24713 Cover assembly
2 24712 Enclosure
3 24836 Instrument bracket
4 25765 Connector plate
5 25428 Power terminal block plate
6 25362 Terminal block; 6 terminals
7 25363 Terminal block plug; 6 terminals
8 10919 Lock washer int. tooth No. 4
9 10890 Machine screw 4-40 x.25
10 25482 Connector; 3 pos.
11 25483 Contact, female
12 25369 Rocker switch
13 11212 Fully insulated quick disconnect
14 11164 Lug
15 25617 Hard Disk Drive
16 25498 Mini keyboard
17 25499 Mouse
18 25212 Disk drive plate
19 25645 Power cord assembly
20 24117 RJ45 - RJ45 cable assembly
25548 Cable Kit Assembly includes:
22 24890 Keyboard extension cable
24 24892 LVDS Data cable assembly
26 24894 LPT cable assembly
27 24895 LCD Backlight cable assembly
30 25404 PS2 Keyboard- Mouse cable assembly
31 25470 USB cable assembly
32 25388 IDE cable assembly
33 12342 O-ring
34 17534 Liquid tight connector
35 25504 Fully insulated quick disconnect
39 26152 Embedded SBC pcb 1GHz
101 24888 Touchscreen controller pcb
123 24891 Touchscreen cable assembly
130 25109Q USB Digital I/O Interface pcb
131 25389Q USB A-B cable assembly
132 25754 Power supply pcb
133 25769Q Sensor power and signal cable assembly
134 25768Q Power and signal cable assembly
135 25387 COM 2 cable assembly
136 25285 Weight controller pcb
137 25213Q Digital I/O mounting plate
138 15745 Knob
139 12621 Retainer washer
140 25793 Weight controller mounting plate
141 15169 3/4” hole plug
142 25347 1/2” hole plug
N/S 25876Q Load cell damped 50 kg capacity 2 mv/v
N/S 94384 Load cell Junction board
N/S 25674Q Source Sensor
N/S 25675Q Detector Sensor
Section 6: Parts List
