Fairbanks IM 6000 Series In-Motion Scale System with FB3000 - Manual (Page 21)

50792 21 05/05 Issue #1
A. Basic Operations Summary
There are two options available, In-Motion Gross Weighing and Static Gross-Tare-Net
Weighing.
1. In-Motion Gross Weighing
a. Press the ZERO key to zero the scale.
b. Place the object to be weighed on the approach conveyor. The object will
be moved by the conveyor onto the scale and where it will pass the On
Scanner. The In-Motion system will begin the weighing process and
derive a weight based upon the In-Motion configuration parameter set-
tings. The final processed weight will be displayed upon the object pass
ing the Off Scanner. The final weight will be stored in the transaction
record file and a record will be sent to a monitoring computer.
2. Static Gross Weighing
a. Press the ZERO key to zero the scale.
b. Place the container on the platform.
c. Manually record the weight.
d. Remove the container from the platform.
Section 4: Operation
