Section 2: Scale Installation

04/10

13 51190 Rev. 2

2.1.4. Positioning the Equipment

Position the equipment with these points in mind:

The scale is to be placed on a flat, solid, level surface, one that fully supports the
weight of the platform plus a full capacity load.

The smooth surface must be within 1/8”, and on a level plane, within ¼” across
both the length and width of the platform.

The four corners of the Platform must rest solidly on the surface, and not rock.
Irregular bumps and foreign material under the Platform can cause an “out-of-
level” condition, which will affect the weight accuracy.

Platform vibrations may also affect the weighing accuracy. Wherever possible,
locate the platform as far away from heavy, low frequency vibrations as much as
possible.

Do not load the platform if there is any evidence of damage to the platform or
supporting structure.

Ease of access is very important. Allow plenty of room for maneuvering a box
truck.

Reading the Indicator is also important to workers, so place it in a very visible
position.

When installing the Scales and Indicator in an outdoor location, set it up so the
snow, ice accumulation, rain and other conditions do not affect the platform
operations.
