A. Mounting:
Mounting the QuickSilver IS Instrument with wall mounting bracket :
1. Choose a location within the length of the cable between the indicator and the
platform.
2. Mount the bracket at eye level of the operator, using SS screws.
3. Attach the indicator to the wall bracket using hardware provided.
4. Route the cable where it is protected.
5. Set platform on a solid, level surface for operation.
B. Assembly:
The QuickSilver IS bench scale is shipped partly disassembled.
To assemble the scale:
1. Carefully remove the packing materials from the box.
2. The scale is shipped in three parts, the platform, the indicator and the pillar. The
platform and indicator are connected with the load cell cable. Remove the three
components and place them on a work surface.
3. The top of the pillar has two (2) mounting flanges in the shape of a “Y.”
Be sure the pillar is in the correct orientation before proceeding.
4. Remove the nuts and lock washers from the weld studs on the bottom of the
Indicator. Place the Indicator on top of the pillar with the two weld studs through
the holes in the top of the pillar. Reinstall the nuts and washers on the weld studs
and tighten them using a 3/8” open-end wrench.
5. Remove the two bolts from the shelf on the back of the platform.
6. Place the pillar upright on the shelf and install the two bolts through the shelf and
the pillar. Thighten the nuts using a 7/16” wrench.
7. Push the excess load cell cable into the QSIS Instrument. Thighten the gland nut.
8. Connect the battery cable to the port in the bottom of the indicator.
9. Assembly is now complete and the scale is ready to operate.
Section 3: Unpacking & Assembly
50770 9 04/12 Rev. 5
