Section 2: Description
50770 6 04/12 Rev. 5
A. Serial Tag Model Legends:
P=Platform
P=Pillar (2nd "P")
I=Indicator or IND = Indicator Only
W=Wall Bracket
H =Hazardous Environment
Example: PWI = Platform + Wall bracket + Indicator
Example: PPI = Platform + Pillar + Indicator
Note: C = CSA approved (Canadian certification)
B. Specifications
1. Minimum Grad Size for Commercial Applications: NTEP Approval = 5000 Divisions
NTEP Appv’d LB KG OZ G
2.0000 X .0001 0.90715 X .00005 32.000 X .002 907.15 X .05
2.0000 X .0002 0.9072 X .0001 32.000 X .005 907.2 X .1
YES 2.0000 X .0005 0.9072 X .0002 32.00 X .01 907.2 X .2
6.0000 X .0001 2.72155 X .00005 96.000 X .005 2721.55 X .05
6.0000 X .0002 2.7215 X .0001 96.000 X .005 2721.5 X .1
6.0000 X .05 2.7216 X .0002 96.00 X .01 2721.6 X .2
6.000 X .001 2.7215 X .0005 96.00 X .02 2721.5 X .5
YES 6.000 X .002 2.722 X .001 96.00 X .05 2722 X 1
YES 6.000 X .005 2.722 X .002 96.0 X .1 2722 X 2
10.000 X .001 4.5360 X .0005 160.00 X .01 4536.0 X .5
YES 10.000 X .002 4.536 X .001 160.00 X .05 4536 X 1
YES 10.000 X .005 4.536 X .002 X .1 4536 X 2
12.000 X .001 5.4430 X .0005 192.00 X .02 5443.0 X .5
12.000 X .002 5.443 X .001 192.00 X .05 5443 X 1
YES 12.000 X .005 5.444 X .002 192.0 X .1 5444 X 2
24.000 X .001 10.8865 X .0005 384.00 X .02 10886.0 X .5
24.000 X .002 10.886 X .001 384.00 X .05 10886 X 1
YES 24.000 X .005 10.886 X .002 384.0 X .1 10886 X 2
YES 24.00 X .01 10.885 X .005 384.0 X .2 10885 X 5
YES 24.00 X .02 10.89 X .01 384.0 X .5 10890 X 10
YES 24.00 X .05 10.88 X .02 384 X 1 10880 X 10
25.000 X .001 11.3400 X .0005 400.00 X .02 113400 X 5
25.000 X .002 11.340 X .001 400.00 X .05 11340 X 1
YES 25.000 X .005 11.340 X .002 400.0 X .1 11340 X 2
30.000 X .001 13.6070 X .0005 480.00 X .02 136075 X 5
30.000 X .002 13.608 X .001 480.00 X .05 13608 X 1
30.000 X .005 13.608 X .002 480.0 X .1 13608 X 2
