Section 6: Battery Pack
* * WARNING! * *
Battery packs are to be charged in non-hazardous areas only!
INPUT VOLTAGES 120 VAC, 60 Hz
BATTERY OUTPUT VOLTAGES 7.0 VDC +/- 0.2 VDC at the end of charge cycle with
battery connected.
LEADS • Output leads 18 AWG, approximately three feet
(3’).
• Extended power cord up to six feet (6’).
STATUS LED Brightness sufficient to discern the charge status
under general office environment lighting.
CHARGING TIME • Sixteen (16) hours maximum for undamaged
chargeable battery (electrolyte not depleted).
• Initial unloaded output voltage of 5.0 VDC.
• Do not recharge a battery with a voltage below
4.0 VDC .
OPERATING 0°C to +38°C (+32°F to +100°F).
50770 17 04/12 Rev. 5
A. Description
Accessory 530 Battery Recharger is a Safe Area
Smart Charger, intended for non-hazardous, safe areas
only. It is only used for recharging Battery Accessory 352.
• This Accessory will fully charge a completely discharged
532 Battery within sixteen (16) hours.
• A charged battery can be left on the charger without any
resulting damage to either the charger or the battery pack.
• When a discharged Accessory 532 Battery is first
connected to a charger, the status LED on the charger will
be a constant yellow.
• Once the battery is fully charged, the LED will remain a
constant green.
IMPORTANT NOTE: Use the Accessory 530 Battery Recharger in a SAFE AREA only.
B. Specifications
