A . Ac c ept R ange Dis play
B . Under R ange Dis play
C . Over R ange Dis play
( Ta rget V alue -
L imit V alue )
( Ta rget V alue -
2 x L imit V alue )
( Ta rget V alue +
2 x L imit V alue )
(T arget V alue -
of th e L imit V alue )
(T arget V alue +
of th e L imit V alue )
( Ta rget V alue +
L imit V alue )
( Ta rget V alue -
3 x L imit V alue )
( Ta rget V alue +
3 x L imit V alue )
P ointe r
6
6
5
5
/
/
2 6 4 5 b
N ot U se d
N ot U se d
N ot U se d
N ot U se d
Note: Target and limit weight values - while values of 0, 1, 2, 3 , or 4 divisions may be
entered as target or limit values during the programming, the system will ALWAYS default to 5
divisions.
Note: When the arrow keys are pressed, Fine adjustment changes the last two digits,
Coarse adjustment changes the first two digits. The operator can toggle between fine and
coarse adjustments by pressing the [UNITS] key.
50770 15 04/12 Rev. 5
f. Over/Under Setup
1. Press the ZERO key and the display will show "0" with the center-of-
zero indicator ON.
2. Press the appropriate OVER/UNDER key, 1, 2, 3, or 4. The display
will flash the last target value entered into memory and then display
the OVER/UNDER graphic.
3. To change the TARGET WEIGHT, press the UP key. The display will
show the current target weight in memory as a four digit number.
4. Press the UP key to increase the target weight or the DOWN key to
decrease the target weight. In some cases, it will be faster to enter a
new target weight or limit weight by starting from 0. Press the ZERO
key. The display will be reset to all zeros. Use the arrow keys and
the UNITS key to enter a new target weight or limit weight.
