FireFinder XLS
6300
s Industry, Inc.
Building Technologies Division
s Catalog Sheet
Fire Safety & Security Products
FireFinder XLS
FireFinder XLS Fire Alarm Control Panel
System Overview
FireFinder XLS is a microprocessor-based, advanced
life-safety system that has a 6" display and large, lighted
buttons – making it the most intuitive fire-alarm user
interface in the industry. Its use of the unique multiprocessor
"Network" design, along with its ability to utilize analog and
conventional detection devices, makes it an extremely
flexible and configurable life-safety system.
XLS is ideally suited for commercial, institutional and
industrial fire detection and notification applications.
XLS complies with the requirements of NFPA
Standard 72, and is listed by Underwriters Laboratories
under their standard UL 864.
Underwriter's Laboratories of Canada also lists the XLS for fire
applications under ULC-S527. XLS is approved by Factory
Mutual; as well as CSFM and NYMEA for use in those specific
locales. In addition to the standard fire applications, XLS is
listed by Underwriters Laboratories under the category UUKL for
smoke control. XLS can be used as a listed Fireman's Smoke
Control Station in high-rise office buildings, malls and other
large structures.
XLS is listed by UL Listed and FM Approved for Sinorix
TM
clean-agent systems and pre-action or deluge sprinkler systems,
which include foam or water applications. XLS follows the
releasing requirements,
specified in NFPA 13 and 2001.
•
Standard 2500 addressable, point-
capacity system
•
Ability to network with other FireFinder
XLS systems
•
Powerful, easy-to-use programming
capabilities
•
Fully field programmable, via Windows®
laptop PC
•
6" Backlit LCD display
•
User-friendly system interface
•
Touch screen for maintenance operations
and function keys
•
Global annunciation and control
capability
•
Multi-language display
•
Universal AC power input:
120VAC, 50/60Hz
•
Support of 220/240VAC, via step-down
transformer
•
12 amps of system power
(expandable to 48 amps)
•
Numerous Relays: Alarm, Trouble,
Programmable, etc.
•
SureWire addressable-loop technology
•
Polarity-insensitive detection circuits
(patented)
•
Useful diagnostic LEDs on all cards
•
Supports FirePrint application-specific
detection
•
Intelligent / analog detection circuits:
Class A or Class B
•
Detector Sensitivity Readout / Printout,
per NFPA 72
•
Supervised remote printer
•
32-character custom messages
•
Thermal strip printer
•
Security-device monitoring ( UL 1076 Listed)
•
Sprinkler Supervision
•
Seismic Certified
•
UUKL Listed for smoke control
•
UL 864 9 th Edition Listed & ULC Listed;
FM, CSFM & NYMEA Approved
•
Multiple command stations
•
Menu-driven operator commands
•
5000-event, history-logging capability
with on-line & off-line reports
•
User help screens
•
Multiple levels of password protection
•
Automatic environmental compensation
for smoke detectors
•
Alarm verification by Device or Zone
•
Logic-controlled output functions
•
Time-based-controlled output functions
•
Holiday schedule
•
City tie / leased line
•
Coded outputs
•
200 notification-appliance-circuits
(NACs) capacity
•
Up to 3.0 amps (24VDC) per NAC
•
Built-in strobe synchronization protocol
•
Supports pre-action, deluge and agent
releasing
•
Voice evacuation system (optional)
•
Modular assembly
•
NEC 760 power-limited circuits
( UL 864 Compliant)
•
Intelligent interface to building / process
management systems
•
Degrade-mode operation
