7.2.2 Real-time display indication mode.
While the mode is in real-time data indication ([D-NO] shows 0, 1 or 2. You can choose
the desired type of data by pressing the [
↓↓↓↓
] and [
↑↑↑↑
] keys to change the [D-NO] (data number).
The indicator will show the following data in "DATA" AND "ANGL.SPNO" for the selected
D-No..
Rotated angle.
Maximum torque (maximum hold).
2
Axis unit number
Torque voltage.
1
Axis unit number
Torque value.
0
ANGL.SPNO
DATA
D-No
PTorque value:
The real-time (current) torque value on the torque
transducer is shown.
PTorque voltage :
The real-time (current) torque signal voltage on the torque
transducer is shown.
PMaximum torque:
The peak torque, measured since the last resetting of the
switch within the current mode, is shown.
PAxis unit number:
The Axis unit No. as set up on the unit via dip switches
PRotated angle:
The real-time angle of rotation of the tool output shaft (in the
fastening direction CW), measured since the last resetting of
the switch within the current mode. (-119
°
to 999
°
).
Key operation during the real-time data indication mode.
Indication shown in "DATA"
D-NO
DATA
0
1
2
TORQUE VALUE
TORQUE VOLTAGE
PEAK TORQUE
(MAXIMUM HOLD)
OR
FIG. 7-2-2 Real time display selection
