7.1.4 Fastening Presetting / Result Display Controls.
wMODE.
PUsed to change modes while in the Run state. (Refer to 7.2)
PUsed to move the cursor while in the Bypass (program) state. (Refer to 7.3)
wSET.
PUsed to enter the Data Edit mode, and to confirm data setting change.
w[ ↑↑↑↑ ] and [ ↓↓↓↓ ] Cursor key (vertical arrows).
PUsed to scroll through available parameter numbers. (PARM)
PUsed to scroll through available data preset items. (D-NO)
PUsed to change display data values. (DATA)
PUsed as YES/NO acknowledge for Tool type and Torque unit changes. (Fig 7-3-8b)
