w1) Tool type input items.
DFT-153N1-O 116
DFT-502M4-O 115
DFT-203N1-O 113
DFT-802W4-O 112
DFT-802M4-O 111
DFT-802M4-OR 310 DFT-302M3-O 110
DFT-302M3-OR 309 DFT-202M3-O 109
DFT-202M3-OR 308 DFT-132M3-O 108
DFT-132M3-OR 307 DFT-801M3-O 107
DFT-801M3-OR 306 DFT-401M2-O 106
DFT-401M2-OR 305 DFT-401M1-O 105
DFT-401M1-OR 304 DFT-201M1-O 104
DFT-201M1-OR 303 DFT-101M1-O1 103
DFT-101M1-OR 302 DFT-101M1-O 102
DFT-051M1-OR 301 DFT-051M1-O 101
DFT-153N1-S 16
DFT-502M4-S 15
DFT-403N1-S 14
DFT-203N1-S1 13
DFT-802W4-S 12
DFT-802M4-S 11
DFT-802M4-SR 210 DFT-302M3-S 10
DFT-302M3-SR 209 DFT-202M3-S 9
DFT-202M3-SR 208 DFT-132M3-S 8
DFT-132M3-SR 207 DFT-801M3-S 7
DFT-801M3-SR 206 DFT-401M2-S 6
DFT-401M2-SR 205 DFT-401M1-S 5
DFT-401M1-SR 204 DFT-201M1-S 4
DFT-201M1-SR 203 DFT-101M1-S1 3
DFT-101M1-SR 202 DFT-101M1-S 2
DFT-051M1-SR 201 DFT-051M1-S 1
TOOL NAME TOOL
NUMBER
TOOL NAME TOOL
NUMBER
2) Fastening mode and fastening steps.
CCW ANGLE CONTROL, 2 STEP. 0121
CCW TORQUE CONTROL, 2 STEP. 0120
CCW ANGLE CONTROL, 1 STEP. 0111
CCW TORQUE CONTROL, 1 STEP. 0110
CW ANGLE CONTROL, 2 STEP. 0021
CW TORQUE CONTROL, 2 STEP. 0020
CW ANGLE CONTROL, 1 STEP. 0011
CW TORQUE CONTROL, 1 STEP. 0010
FASTENING MODE / STEPS SET VALUE
