FREE RUN REVOLUTIONS 60 1~8 Revolutions
REVERSE SPEED 54 1~8
TORQUE SPEED 53 1~8
SLOW DOWN SPEED 52 1~8
FREE RUN SPEED 51 1~8
INITIAL SPEED 50 1~8 Speed
FINAL TIME 42 1~8
1ST STEP TIME 41 1~8
INITIAL TIME 40 1~8 Time
2ND TORQUE RATE HIGH LIMIT 33 1~8
2ND TORQUE RATE LOW LIMIT 32 1~8
1ST TORQUE RATE HIGH LIMIT 31 1~8
1ST TORQUE RATE LOW LIMIT 30 1~8 Rate
CROS ANGLE (2nd torque rate start). 24 1~8
1ST ANGLE 23 1~8
STD ANGLE 22 1~8
HIGH ANGLE LIMIT 21 1~8
LOW ANGLE LIMIT 20 1~8 Angle
CROS TORQUE 18 1~8
THR TORQUE 17 1~8
SNUG TORQUE 16 1~8
1ST TORQUE 15 1~8
CCW angle, 2 step 0121 SPEED CHANGE 14 1~8
CCW torque, 2 step 0120 STD TORQUE 13 1~8
CCW angle, 1 step 0111 TORQUE HIGH LIMIT 12 1~8
CCW torque, 1 step 0110 TORQUE LOW LIMIT 11 1~8
CW angle, 2 step 0021 FULL SCALE TORQUE 10 1~8
CW torque, 2 step 0020 STEP 02
CW angle, 1 step 0011 FASTENING METHOD 01 1~8
CW torque, 1 step 0010 FASTENING MODE (method + steps) 00 1~8 Torque.
PARAMETER 8 TOOL # 28 0
PARAMETER 7 TOOL # 27 0
PARAMETER 6 TOOL # 26 0
PARAMETER 5 TOOL # 25 0
PARAMETER 4 TOOL # 24 0
PARAMETER 3 TOOL # 23 0
PARAMETER 2 TOOL # 22 0
PARAMETER 1 TOOL # 21 0
TOOL # (When parameters use the
same tool). 20 0 Tool type.
1A
4: inlb COMPANY'S SUPERVISOR DATA. 12 0
3: ftlb TOOL CAL TORQUE. 11 0
2: kgcm TOOL # (not adjustable) 10 0 Tool Data.
1: Kg.m ROM VERSION (Not adjustable) 01 0
0: Nm TORQUE UNIT #. 00 0 System.
DATA
***
D- No
**
*
PARM
No.
ITEM
* Displayed in PARM/ABN display. ** Displayed in D-NO display. *** Display in DATA display.
Chapter 7: System Operations (Rev. 8/98)
Page 7-10
