APPENDIX
TO PRINT STORED READINGS (KEY 5) - OPTIONAL
1.
On the back of the instrument is a “serial output” receptacle for connection to a serial
(RS-232C) printer (see Note). The RS-232C data output format is as follows: 1 start
bit, 8 data bits, and 1 stop bit, at a rate of 300 baud (bits/sec.). A connecting cable is
available from TBE/AI when using a standard serial printer with the analyzer. To use
the printer, proceed as follows:
Plug the cable into the MAX 5 “serial output” receptacle and the printer
(see Figure 3).
Align
the paper.
Turn the power on.
Press the “FF (Form Feed)/Auto Sheet Load” button to advance the paper one
sheet.
Press the “ONLINE” button.
NOTE: If the printer is purchased from TBE/AI, refer to the printer “instruction manual” for set
up. If the printer is not purchased from TBE/AI, any serial printer may be used if it complies
with the following minimum specifications:
a. It can accept RS-232C serial data in the speed and format shown.
b. It has a standard 25 pin RS-232C connector, so it can be used with the
optional factory-supplied cord).
c. It has a minimum print speed of 50 characters per second (cps).
d. It has an input buffer of at least 1024 bytes (1Kb).
