Appendix Model 3220
Teledyne Analytical Instruments 40
Appendix
A-1 Specificationss
Range: 0-25%, 0-100% Oxygen
Number of Channels: Up to eight channels
Repeatability:
2 % of full scale
Accuracy: ±2% of full scale at constant temperature
±5% of full scale over the working
temperature range
Response Time: 90% in less than:
B3 -- 13 seconds
B1 -- 7 seconds
A3 -- 45 seconds
A5 -- 45 seconds
Operating Temperature: 0 to 50 o C
Alarms: Two Adjustable Alarm Point plus Failure
Alarm Indicators illuminate at Alarm
Setpoint.
Alarm 1-RED
Alarm 2-AMBER
Fail-BLUE.
Signal Output: Internal: LCD Display
External: 0-10 VDC or 4-20 mA
negative ground (user-configurable)
Power Requirements: 100-240 VAC 50/60 Hz
