3 Installation Model 3220
Teledyne Analytical Instruments 16
Installation
Installation of the analyzer includes:
1. Unpacking the system
2. Mounting the Channel Module and Control Module
3. Making the electrical connections
5. Making the gas connections
6. Testing the installation
3.1 Unpacking the Analyzer
Each TAI Model 3220 Oxygen Gas Monitoring System is generally
shipped with the channel modules and control module installed.
Carefully unpack the analyzer and inspect it for damage. Immediately
report any damage to the shipping agent.
3.2 System Chassis
The physical dimensions and mounting hole spacing for the System
Chassis are given on Drawing C-68499 . The System Chassis is
designed to fit into a standard 19" rack. It requires 7" panel height and
12.3" depth plus allowance for cabling behind the panel.
3.2.1 Location
The System Chassis is designed for installation in a NON
HAZARDOUS Environment.
3.2.2 Power
The model 3220 is designed to operate from 100/240VAC @ 50/60
Hz. Ventilation must be provided to dissipate heat generated within the
control unit. Natural convection is sufficient to cool 16 Channel
Modules. However, if more are mounted in the same chassis, forced
ventilation should be used.
