Specifications and Dimensions
Vertical SteamPacs
Specifications – Fulton Vertical SteamPacs from 10 to 100 HP
Models FT
010X
015X
020X
030X
040X
050X
075X
100X
Steam Output*
LB/HR
KG/HR
345
157
517
235
690
313
1,035
470
1,380
626
1,725
783
2,587
1,174
3,450
1,565
Input
BTU/HR (1000)
KCAL/HR (1000)
335
84
502
126
669
169
1,017
256
1,339
337
1,674
422
2,678
675
3,347
843
Flow Rate
GPM
M3/HR
23
5.2
35
8
46
10.5
69
16
92
21
114
26
171
39
228
52
*From and at 212
o
F (100
o
C). Steam Output is based in a minimum thermal fluid temperature of 425
o
F (218
o
C)
Dimensions – Fulton Horizontal SteamPacs from 10 to 100 HP
Models FT
010X
015X
020X
030X
040X
050X
075X
100X
A. Width
IN
MM
84
2,134
72
1,829
92
2,337
92
2,337
92
2,337
92
2,337
92
2,337
92
2,337
B. Length
IN
MM
72
1,829
84
2,134
72
1,829
72
1,829
72
1,829
72
1,829
92
2,337
92
2,337
C. Height
IN
MM
125
3,3175
125
3,3175
125
3,3175
125
3,3175
143
3,632
143
3,632
169
4,93
169
4,293
All dimensions are based on 550oF thermal fluid temperature and are subject to change based on
specific customer requirements. Vertical SteamPac dimensions include feedwater tank and blowdown separator.
All SteamPac accessories including feedwater tanks, feedwater pumps, blowdown separators,
chemical feed and water softeners are available from Fulton.
