13
Aligning appliance door
In the cooling appliances, previously load
the door tray.with approx. 5 kg (eg with
bottles of drink).
Release screws Fig. 8/1, align door.
ReĆtighten screws. Push covering caps
Fig. 8/2 over the hinges.
Assemble door handles
Fig. 9
(A Torx T20 screwdriver will be needed).
The handle can be attached to the
appliance door in different places. When
assembling, compare the hole distances
of the handle to the hole distances of the
decorative trim. There, where the distance
coincides, the handle can be screwed on.
Electrical connection
The socket should be easily accessible.
The best position is above the highĆsided
unit. Operate the appliance only when
installed.
When inserting the appliance into the
highĆsided unit, ensure that the mains
cable is not pinched.
Connect the appliance to 220-240 V/50
Hz alternating current via a correctly
installed earthed socket.
The socket must be fused with a 10 A
fuse. If the appliance is to be operated in a
nonĆEuropean country, the supply
voltage, current type and frequency of the
appliance must correspond with the
specifications of your power supply. The
rating plate is situated in the bottom
leftĆhand side of the appliance.
The mains connection cable may only
be replaced by an electrician.
Ventilation
Figs. 0, q, w and e
The appliance must have a ventilation
opening in the base and a ventilation shaft
at the rear of the highĆsided unit.
Minimum cross section of the
ventilation openings in the base and at
the rear of the highĆsided unit
200 cm 2 .
Installation dimensions
Fig. 0
We recommend a cavity depth
of 560 mm.
Dimension
A
(mm)
Dimension
B
(mm)
Refrigerator
874
1021
1221
876 +4
1025 +4
1225 +4
Freezer 712
874 716 +4
876 +4
Fig. q
Refrigerator
874 mm tall
Freezer 712 mm tall
Fig. w
Refrigerator
874 mm tall
Freezer 874 mm tall
Fig. e
Refrigerator
1021 mm tall
Freezer 712 mm tall
= Socket installation area
