- 12 -
SPECIFICATIONS
Table 5 Line Mode Specifications
MODEL IPS5000R IPS5000L
Input Voltage Waveform Sinusoidal (utility or generator)
Nominal Input Voltage 230Vac
Low Line Disconnect
170Vac (Normal)
90Vac (generator/Wide range)
Low Line Re-connect
180Vac (Normal)
100Vac (generator/Wide range)
High Line Disconnect 280Vac
High Line Re-connect 270Vac
Max AC Input Voltage 300Vac rms
Nominal Input Frequency 50Hz / 60Hz (Auto detection)
Low Line Frequency Disconnect 40±1Hz
Low Line Frequency
Re-connect
42±1Hz
High Line Frequency Disconnect 65±1Hz
High Line Frequency Re-connect 63±1Hz
Output Voltage Waveform As same as Input Waveform
Output Short Circuit Protection Circuit Breaker 40A
Efficiency (Line Mode) >95%
Transfer Switch Rating 40A
Transfer Time
(AC to DC) 10ms (typical)
20ms (typical)
Transfer Time
(DC to AC) 10ms (typical)
20ms (typical)
Power Limitation
Input Voltage
Max Output power
5KVA/4.2KW
2.5KVA/2.1KW
90V 180V
