Ricoh Aficio SP 4110N User Manual
Page 37
6.
Attach the antenna to the card with the label facing down and the uneven side of the antenna
facing up.
AET096S
7.
Insert the card slowly into the interface unit with the label facing down and the uneven black
antenna surface facing up until it stops.
AUB214S
8.
Attach the antenna cap to the card with the side that has both corners of the antenna cap
cut out facing the screws.
AUB241S
• Use a coin or similar object if the screws do not turn easily.
Attaching IEEE 802.11b Interface Unit
35
2
