Ricoh Aficio SP 4110N User Manual
Page 122
4.
Push the under board levers ( ), and then pull the duplex unit out of the printer ( ).
AUB319S
5.
Move the printer to the edge of a sturdy and stable table or desk.
AUB308S
6.
Slide the green lock lever to the left ( ), and then remove the paper feed roller ( ).
AUB309S
6. Replacing Consumables and Maintenance Kit
120
6
