10. Fasten the controller board to the printer with the two screws.
AUB209S
• Use a coin or similar object if the screws do not turn easily.
• After finishing the installation, you can check the memory unit is properly installed: Print the
configuration page from the [List/Test Print] menu. If it is installed properly, the memory capacity will
appear under "Total Memory" on the configuration page.
• The table below shows the total SDRAM module capacities.
Standard Extended Total
128 MB *1 128 MB 256 MB
128 MB *1 256 MB 384 MB
• *1 Value when the default SDRAM module (64 MB) is removed
• If the memory unit is not properly installed, repeat this procedure. If you cannot install it properly even
after reinstallation, contact your sales or service representative.
• Install the controller board carefully to prevent any malfunction.
• "Printing the Test Page", Quick Installation Guide.
2. Installing Options
