Attaching Memory Unit Type C 128MB/
256MB (SDRAM Module)
• Do not touch the inside of the controller board compartment. Doing so may cause a malfunction or a
burn.
• Before touching the memory unit, ground yourself by touching something metal to discharge any static
electricity. Static electricity can damage the memory unit.
• Do not subject the memory unit to physical shocks.
• Before using the new memory unit, Be sure to make settings in the printer driver.
• Remove the default SDRAM module (64 MB) before installing the optional SDRAM module.
1. Turn off the power of the printer, and then unplug the power cable and interface cable.
2. Remove the two screws holding the controller board in place.
AUB202S
The removed screws are required in fastening the controller board.
3. Pull out the handle of the controller board.
AUB203S
