Internal connections of the electrical heating
NOTE:
Other executions are available as options.
3 AC
1 AC
Technical remarks
Heating
3x230V
R5
3x400V
R5
4,2kw
3x1,4kw
See Label 14
LC1D0901
See Label 15
LC1D0901
6kw
3x2kw
See Label 14
LC1D0901
See Label 15
LC1D0901
9kw
3x3kw
See Label 14
LC1D1810
See Label 15
LC1D0901
12kw
3x4kw
--------
--------
See Label 14
LC1D0901
12kw
3x2kw
3x2kw
See Label 14
See Label 14
LC1D1810
LC1D1810
See Label 15
LC1D1810
15kw
3x2kw
3x3kw
See Label 14
See Label 14
LC1D1810
LC1D1810
See Label 15
LC1D1810
18kw
3x3kw
3x3kw
See Label 14
See Label 14
LC1D1810
LC1D1810
See Label 15
LC1D1810
21kw
3x3kw
3x4kw
--------
--------
See Label 15
See Label 14
LC1D1810
LC1D1810
24kw
3x4kw
3x4kw
--------
--------
See Label 14
See Label 14
LC1D1810
LC1D1810
27kw
3x3kw
3x3kw
3x3kw
See Label 14
See Label 14
See Label 14
LC1D1810
LC1D1810
LC1D1810
See Label 15
See Label 15
See Label 15
LC1D1810
LC1D1810
LC1D1810
36kw
3x4kw
3x4kw
3x4kw
--------
--------
See Label 14
See Label 14
See Label 14
LC1D1810
LC1D1810
LC1D1810
Heating
R5
3kw
LC1D0901
B = Black
Br = Brown
Gy = Grey
Bu = Blue
R = Red
W = White
Table 7
Table 8
"Delta" configuration
"WYE" configuration
